Duct-Out Version:
Vapours are evacuated outside through an exhaust pipe attached to the connecting flange.
CAUTION! If the product features one or more carbon filters, they must be removed.
Connect the product to wall-mounted exhaust pipes and holes with a diameter equivalent to the air outlet (connecting
flange).
The use of pipes and outlet holes in the wall with a smaller diameter will reduce the extraction performance and drastically
increase the noise level.
All responsibility in this regard is therefore denied.
• Use a ducting pipe with the shortest length necessary.
• Use a ducting pipe with the least number of bends possible (maximum bend angle: 90°).
• Avoid drastic changes in the ducting pipe diameter.
●
Recirculating Version:
The suctioned air will be degreased and deodorised before it is sent back into the room. To use the product in this version,
it is necessary to install an additional activated carbon filter system.
ASSEMBLY BEFORE INSTALLATION
• Check that the product is the right size for the installation area.
• Remove the activated carbon filter(s) if supplied (see also relevant paragraph).
• It(they) must be reinstalled if the product is used in the filter version.
• If there are panels and/or walls and/or wall units on the sides, make sure that there is enough space to install the product
and that it is always possible to access the control panel easily.
• The product is equipped with fixing plugs suitable for most walls/ceilings. However, it is necessary to consult a qualified
technician to make sure that the materials are suitable for the type of wall/ceiling. The wall/ceiling must be strong enough
to support the weight of the hood.
Tips and requirements for optimal use of the NO DRIP SYSTEM
This product has been designed in such a way as to prevent the formation of condensation on its lower surfaces when it is
placed on top of an induction hob.
Unlike gas or electric hobs, induction hobs only heat the food containers and not the surrounding air, so the surfaces of
the hood are cold.
When the hot cooking fumes rise, they meet the cold surfaces of the hood, condense and then release the moisture in the
air, which quickly turns into drops
of water, which then inevitably fall onto the hob and onto the food, bringing grease and impurities with them.
Thanks to the inclined lower surface of the hood, any condensation flows into a special tray.
• For maximum performance of the NO DRIP SYSTEM, when cooking high moisture foods, it is advisable to use the hobs
at the back.
• The grease filters should not be removed once cooking has terminated to allow time for the collected condensation in the
grease filter to settle in the tray.
• The rate of condensation collection increases with increasing suction speed (power).
• The NO DRIP SYSTEM offers the best performance in an environment with a temperature between 18°C and 25°C.
• Always open the steam collector (panel) to its full range of motion.
ELECTRICAL CONNECTION SAFETY
•The mains voltage must correspond to the voltage indicated on the label found inside the product. •If it features a plug,
connect the product to a socket that complies with current standards, located in an area accessible even after installation.
•If it does not feature a plug (direct connection to the mains) or the plug is not located in an accessible area, even after
installation, apply a standard double pole switch that ensures complete disconnection from the mains in category III
overvoltage conditions, in accordance with the installation rules. •The product features a special power cable; if the cable
is damaged, contact the Service Centre for a replacement.
● Please note! Before reconnecting the circuit to the mains power supply, make sure that it is working correctly, always
check that the power cable is correctly installed.
