with „+" and „-" at designated slots.
Activation/Operation
By pressing the call button (Fig. A5), an acoustic signal
is triggered at the indoor units and the monitors turn on.
You can speak with the guest by briefly pressing on the
talk button (Fig. A13). The talking time is approximately
120 seconds. You can end the conversation at any
time by pressing again the talk button. Without user
activity the panel automatically switches to stand-by
mode after about 40 seconds. Press the door opener
button (Fig. A12) in order to open the door. By pressing
the monitoring function (Fig. A11) you can monitor at
any time the area covered by the camera. After about
40 sec. the system switches back in stand-by mode.
You can adjust the brightness (Fig. A15) and contrast
(Fig. A16) of the screen, by adjusting the control dial.
Between the 16 polyphonic ringtones you select by
pressing the ringtone selection button (Fig. A10). The
same applies for the volume control (Fig. A9). Confirm
your entries each with a press of the talk button (Fig.
A13).
Expansion options/Intercom Function
You can extend this system with one indoor unit
„per floor"/party (Order.-No.: 088481). Within this
extension an internal call (intercom) is possible.
Just press the intercom button on any monitor
(Fig. A13). This sends a signal to the paired device(s).
Troubleshooting
Problem
No power
(no picture on monitor)
Power is on, but no picture on the
monitor
The picture is too dark or white
Chime sound is too low
Technical information
Indoor unit (88337)
Supply voltage
Rated power
Stand-by
Monitor
Resolution
Operating temperature
Dimensions
Power Supply (for each indoor monitor)
Input voltage
Output voltage
Rated current
Outdoor Unit (8834403)
Camera
Operating temperature
Mounting method
Door opener
Dimensions
Technical and design features may be subject to change without notice.
Call acceptance is by pressing the speaker button
(Fig. A11). The conversation can be terminated by
both parties by pressing again the speaker button!
Only calls between two stations can be performed.
In the extensions stage with 3 indoor units you may
The intercom option only works within a residential
unit between two directly connected units (Fig. A20).
Simultaneous calls are possible only between two
stations.
Other Notes
Do not install the indoor units where they are exposed
to high temperatures and humidity or in the vicinity
of TV sets. Do not touch the sensor buttons with wet
hands. To clean the monitor or the camera, do not use
cleaning agents. Simply use a damp cloth. Do not
install the camera and the indoor unit in occurrence
of direct light. Do not install near electronic devices
(TV, Computer, telephones), as this may lead to
disturbances of the system.
Recycling instructions
This device may not be disposed of with unsorted
household waste. Owners of old devices are
required by law to dispose of this device correctly.
Contact your town council for further information.
Check point
• Is the power supply connected correctly?
• Is the cable firmly connected between the monitor and the
camera?
• Is the polarity of wires correct between the outdoor camera
unit and indoor monitor unit?
• Adjust brightness control
• Adjust the volume control
Specifications
DC 15 V
operation max 10 W
< 0.1 W
TFT-LED 102 mm diagonal screen size
320 x 240 pixels
approx. -5 °C to 40 °C
approx. W 125 x H 190 x D 26 mm
Specifications
230 V~, 50 Hz
DC 15 V
1.2 A
Specifications
CCD sensor > 420 TV lines
approx. -20 °C to +50 °C
surface mounted
max. 12 V/1.0 A
approx. W 85 x H 142 x D 38 mm
8
need to call again to reach the third user. The
maximum talking time for internal calls is 40
sec.
