To secure the tow bar, the tow eyes of the vehicles must first be
made ready if required; with regard to this, please follow the manufacturer's
connecting hook (1) of the tow bar must now be opened; to do so, press the two push buttons of the
connecting hook (2). Now, the connecting hook (1) can be shifted and thereby opened. If necessary,
now you can also fully remove the connecting hook (1) and secure it to the tow eyes of the vehicle
concerned. Make sure that the connecting hook (1) is inserted into the tow eye of the vehicle absolutely
from above, surrounding it safely. Then slide the connecting hook (1) back to its original position on the
hook rod (3) until the push buttons (2) firmly snap into the corresponding
Proceed with the connecting hook (4) Of the second hook rod (7) on the second vehicle exactly in the
same way as previously described. Now only the two hook bars (3 and 7), already coupled with the
vehicles, must be connected to the tow bar with the help of the red centrepiece (5) TO do so, slide the
red centrepiece
already been snapped into place, they must be pressed again so as to further push the tow bar. (see
Image 2) This is necessary to connect the hook bar (7), already secured to the other vehicle, to the red
centrepiece
Slide also the second hook rod (7) into the red centrepiece
place. When cautiously and slowly starting up the vehicle, the tow bar is automatically
the last two push buttons (6) snap into place
After the initial start-p, immediately
been fully snapped into place on the entire tow bar When towing, please strictly comply with the safety
instructions provided at the beginning of this manual.
Separating
First, both vehicles must be secured against rolling away Only then may the tow bar connecting hooks
C (1) and (4) be released from the tow eyes. For this purpose, press the two push buttons (2) of the
connecting hook (1) and release the hook by shifting the tow eye. It may be necessary to also press the
M two push buttons (6) on the connection between the red centrepiece (5) and the hook bar (3) in order to
release the connecting hook (1) from the tow eye of the vehicle.
Y
When releasing the second vehicle connecting hook, proceed exactly in the same way as for the first
vehicle
CM
carrying bag
MY
CY
CMY
K
Clean the tow bar with a slightly damp, soft cloth and a mild detergent. Make sure that no cleaning
agent or liquid penetrates into the tow bar. Do not use harsh detergents, solvents, petrol, etc.
Store the tow bar in a dry place
When the tow bar is visibly damaged, its safe operation is no longer possible
please contact your dealer or our service department.
Tow bars should be disposed Of separately from household waste Please contribute to protecting the
environment and dispose of the tow bar according to local regulations, e.g. at a recycling centre
(5) onto the hook rod (3) already connected to the vehicle. If the push buttons (6) have
(5)
stop again and make sure all eight pushbuttons
the vehicles
Always stow away all the tow bar parts together with these instructions in the included
MAINTENANCE
RESPONSE
OPERATION
holes
(5) until the two push buttons (8) snap into
STORAGE
TO MALFUNCTIONS
DISPOSAL
instructions. The
pulled apart until
(2, 6, 8, 9) have
In case Of any doubt,
