RESERVE RD1 Bedienungsanleitung Seite 4

Right Red:
Brake housing routing.
Right Green:
Rear derailleur cable routing,
chainring setup.
Widths Available:
Handlebar Diameter: 31.8mm integrated
Clamp Compatibility: 1-1/8"
Maximum Torque (Steerer Clamp): 5 Nm
Maximum Torque (Top Cap): 5 Nm
SPECIFICATIONS
Material: High Modulus Carbon Fiber
380mm/400mm/420mm/440mm (Center-to-Center)
Stem Lengths: 90mm / 100mm / 110mm / 120mm
Weight: 320–380g (depending on size)
Left Green:
Front derailleur cable routing,
2x chainring setup.
Left Red:
Brake housing routing.
