SELECTING THE ACTION MODE
CAUTION:
Always set the ring correctly to your desired mode mark. If you operate
the tool with the ring positioned halfway between the mode marks, the
tool may be damaged.
1- Action mode changing ring
2- Adjusting ring
3- Graduation
4- Arrow
This tool has three action modes.
.
Drilling mode (rotation only)
.
Hammer drilling mode (rotation with hammering)
.
Screwdriving mode (rotation with clutch) Select one mode suitable for
your work. Turn the action mode changing ring and align the mark that
you selected with the arrow on the tool body
Action mode
changing ring
ADJUSTING THE FASTENING TORQUE
The fastening torque can be adjusted in 18 steps by turning the adjusting
ring so that its graduations are aligned with the pointer on the tool body.
The fastening torque is minimum when the number 1 is aligned with
the pointer and maximum when the marking is aligned with the pointer.
Adjusting Ring
Graduation
1 3 5
Arrow
21
