Representation of the machine
Front View
(1)
Green LED for genuine banknotes
(2)
White LED for active device
(3)
Red LED for suspicious banknotes
(4)
DIR / ADD – button
(5)
ON-OFF / CLEAR – button
(6)
REPORT – button
(7)
Input shaft / Output shaft front
(8)
Viewing how the banknotes must be inserted in
the unit. Please note, that all notes were put on
the right side into the unit.
Display
(9)
Display „Value" for total amount
(10) Display „Denomination" for single amount
(11) Output of tested notes: rear side
(12) Output of tested notes: front side
(13) Display of the single value from the last note or
total amount of all tested notes.
(14) Display of the currency from the last tested note
(15) Error message
(16) Numbers of tested notes in the Value mode and
amount of the actual denomination in the report
mode
(17) Display „DEN" for single value and „ADD" for
total value
Reverse Side
(18) Output shaft rear
(19) Power connection
(20) Update interface Mini-USB
(21) Cover for accumulator
(Underside of the device)
CashConcepts
CCE 112 MULTI
10
