Occhio Sento letto Montageanleitung Seite 38

Installation
230 V AC
mains cable
Wall mounting: Orient
the threaded holes
vertically.
10
5 cm
Cut the mains cable to a length of
5 cm and strip the insulation from
the ends.
Place the mounting plate over the
power outlet and against the wall,
and turn it until the elongated ho-
les are oriented as required. Mark
the positions where the holes are
to be drilled. Orient the threaded
holes vertically.
Check the routing of the power
cables.
Drill two 6 mm diameter holes,
push in the rawlplugs so that they
lie flush and screw on the moun-
ting plate (screws and rawlplugs
are included in the scope of deli-
very). Ensure that the screws finish
flush with the mounting plate.
