All manuals and user guides at all-guides.com Mito largo Montageanleitung / Bedienungsanleitung Mounting instructions / Operating instructions...
Seite 2
All manuals and user guides at all-guides.com...
Step 2 Steuerung Control via » touchless control « + » air « via » touchless control « + » air « mit der Occhio air App using the Occhio air app using the Occhio air controller mit dem Occhio air controller (optional)
All manuals and user guides at all-guides.com Sicherheitshinweise Lesen Sie die Montage-/ Gebrauchs anweisung sorgfältig durch, bevor Sie die Leuchte Dieses Zeichen macht Sie auf installieren. Beachten Sie die Situationen aufmerksam, bei Sicherheitshinweise in dieser denen Sie direkt in das Licht der Anleitung genau und bewahren LED blicken könnten.
All manuals and user guides at all-guides.com Safety precautions Read through the mounting/ use instructions carefully before installing the luminaire. Follow This symbol draws your attention to the safety precautions in these situations in which you could look instructions closely and keep the directly into the light of the LED.
über Netzteil (Konverter) an 230 V AC / 50 Hz Netzspannung, head für Wartungszwecke abnehmbar. Leistung 60 W, Steuerung via » touchless control « (Gestensteue- rung am head, deaktivierbar) oder mit Occhio air. Weitere Versionen: Mito raggio (Bogenleuchte) * Produktionstoleranz ± 50 mm...
(converter), removable head for maintenance purposes. Luminous power 60 W, control via » touchless control « (gesture control on the head, can be deactivated) or with Occhio air Other versions: Mito raggio (arc luminaire) * production tolerance ± 50 mm...
Seite 8
All manuals and user guides at all-guides.com...
All manuals and user guides at all-guides.com Montage Mounting...
Seite 10
All manuals and user guides at all-guides.com Montage / Mounting...
Seite 11
All manuals and user guides at all-guides.com body head Netzteil / power supply base...
Seite 12
All manuals and user guides at all-guides.com Montage / Mounting Reihenfolge der Pakete beachten! Pay attention to the order of the packages!
Seite 13
All manuals and user guides at all-guides.com...
Seite 14
All manuals and user guides at all-guides.com Montage / Mounting Verpackung der base wie Open base packaging abgebildet öffnen. as shown. Schutzcover der base nicht Do not remove the protective entfernen! cover!
Seite 15
All manuals and user guides at all-guides.com 1 base anheben 1 lift the base 2 Einleger entnehmen 2 remove inlays 3 Einleger wie abgebildet 3 prepare inlays aufstellen as shown...
Seite 16
All manuals and user guides at all-guides.com Montage / Mounting Einleger in die Aussparungen Insert the inlays in the einsetzen. recesses.
Seite 17
All manuals and user guides at all-guides.com Die untere Lasche der Turn down the lower flap of Ver packung umklappen. the packaging. Erst jetzt kann die base auf Only now can the base be den Stützen abgelegt werden! placed on the supports!
Seite 18
All manuals and user guides at all-guides.com Montage / Mounting Die Standardeinstellung The default setting (height) (Höhe) ist medium, wie die is medium, to change the Einstellung verändert werden setting show the following kann zeigen die folgenden steps. Schritte. medium high 1,3 m 1,45 m...
Seite 19
All manuals and user guides at all-guides.com Schrauben lösen, Höhen Loosen screws, turn height einstellung drehen und adjustment and fix again. wieder befestigen.
Seite 20
All manuals and user guides at all-guides.com Montage / Mounting Den body wie abgebildet mit dem Kabel zuerst durch die Öffnung führen. First guide the body through the opening with the cable as shown.
Seite 21
All manuals and user guides at all-guides.com Kabel durch die Zugent Guide the cable through lastung führen. the strain relief. Verdrehsicherung und Mount torsion protection Mutter befestigen. and nut.
Seite 22
All manuals and user guides at all-guides.com Montage / Mounting Mit Steckschlüssel und Schrauben zieher fixieren (nur handfest anziehen). Tighten with socket wrench and screwdriver (hand tighten only).
Seite 23
All manuals and user guides at all-guides.com Leuchte am unteren Teil des Lift the luminaire on the body anheben, Verpackung lower part of the body and entfernen. remove the packaging.
Seite 24
All manuals and user guides at all-guides.com Montage / Mounting...
Seite 25
All manuals and user guides at all-guides.com Leuchtenstecker auf der Insert the luminaire plug Unterseite des Stecker on the bottom of the power netzteils einsetzen. supply unit.
Seite 26
All manuals and user guides at all-guides.com Montage / Mounting Kabel, bis die gewünschte Länge erreicht ist, aufwickeln. Wrap the cable until the Wrap the cable until the desired length is reached. desired length is reached.
Seite 27
All manuals and user guides at all-guides.com Schutzcover von body, base und Netzteil entfernen. Remove protective cover from body, base and power supply.
Seite 28
All manuals and user guides at all-guides.com Montage / Mounting upper body auf lower body stecken. Put the upper body to the lower body.
Seite 29
All manuals and user guides at all-guides.com upper body auf lower body stecken. Put the upper body to the lower body. Stecker in die Buchse stecken. Plug the connector into the socket.
Seite 30
All manuals and user guides at all-guides.com Montage / Mounting upper body wie abgebildet ausrichten. Align upper body as shown.
Seite 31
All manuals and user guides at all-guides.com Den head aufstecken (evtl. leicht eindrehen) und fixieren. Sicherstellen, dass der head wirklich fixiert ist! Put on (poss. smoothly turn in) and fix the head. Make sure the head is really fixed!
Seite 32
All manuals and user guides at all-guides.com Montage / Mounting Falls notwendig kann der head über die Feinjustierung ausgerichtet werden. If necessary, the head can be aligned via the fine adjustment.
Seite 33
All manuals and user guides at all-guides.com Die Gabel des head ist kein Gelenk sondern nur zur Feinjustierung vorgesehen! The fork of the head is not a joint, it is only intended for fine adjustment!
Seite 34
All manuals and user guides at all-guides.com Montage / Mounting Die Leuchte ist nun fertig montiert. The luminaire is now completely assembled.
Seite 35
All manuals and user guides at all-guides.com...
Seite 36
All manuals and user guides at all-guides.com...
All manuals and user guides at all-guides.com Steuerung Funktionen / Steuerungs- möglichkeiten der Leuchte. Control Functions / control options of the luminaire.
All manuals and user guides at all-guides.com Steuerung via » touchless control « + » air « Control via » touchless control « + » air « on / off bewegen / move your hand dimmen / halten / keep your hand still up / down fading lange halten / keep your hand still for a time...
Seite 39
Steuerung via Occhio air, weitere Informationen ab Seite 41. Steuerung via Occhio air, weitere Informationen ab Seite 41. Control via Occhio air, for further information see page 41. Control via Occhio air, for further information see page 41. Die Funktion » touchless control « kann via Occhio air deaktiviert werden, weitere Informationen auf Seite 48.
Seite 40
All manuals and user guides at all-guides.com...
All manuals and user guides at all-guides.com Steuerung mit der Occhio air App (optional) Control using the Occhio air app (optional) Quick guide 3 neue Geräte gefunden / Die Occhio air Produkte lassen sich Zurück / Grupp Found 3 new devices...
All manuals and user guides at all-guides.com Steuerungsgesten den / Gruppe / Bearbeiten / my network Group Edit Control gestures QR-C Scan on / off antippen on / off Mito soffitto Mito sospeso dimmen wischen swipe npaired up / down wischen faden * swipe...
Seite 44
All manuals and user guides at all-guides.com Steuerung mit der Occhio air App (optional) Control using the Occhio air app (optional) Nutzung auf mehreren Nutzung auf 1. Netzwerknamen Gruppe / Bearbeiten / Abbrec my network mehreren Geräten vergeben Group Edit Cance Geräten...
Seite 45
All manuals and user guides at all-guides.com 2. Netzwerk Einstellungen / beiten / Abbrechen / Sichern / Gruppe / Bearbeiten / Abbrechen my network freigeben Settings Cancel Save Group Edit Cancel Besucher / 2. Share network Freigabe / Name my network Sharing Passwort / Leuchten in der Nähe anzeigen /...
Seite 46
All manuals and user guides at all-guides.com Steuerung mit der Occhio air App (optional) Control using the Occhio air app (optional) Netzwerk freigeben 2. Netzwerk Einstellungen / Bearbeiten / Abbrechen / Sichern / Gruppe / Bearbeiten / Abbre my network...
Seite 47
Passwort für Besucher Passwort / Visitors password Password E-Mail des Netzwerk- Administrator / Administrator Administrators (zur Wiederherstellung des E-Mail / john.doe @ occhio.de e-mail Netzwerks) e-mail of the network Passwort / administrator (for the Password restoration of the network) Netzwerkkonfiguration Passwort für Administrator...
All manuals and user guides at all-guides.com Steuerung mit der Occhio air App (optional) Control using the Occhio air app (optional) Sensoren deaktivieren Gruppe / Bearbeiten / my network Group Edit Deactivate sensors Name Optional können die Sensoren Symb am head deaktiviert werden.
Seite 49
All manuals and user guides at all-guides.com Geräte in der Nähe / ten / Zurück / Zurück / Mito largo Devices near me Back Back Name Mito largo Bluetooth-Geräte / devices Zum Auswählen drücken / Mito largo Symbol / Icon...
All manuals and user guides at all-guides.com Steuerung mit der Occhio air App (optional) Control using the Occhio air app (optional) Leuchte entkoppeln Decouple luminaire Ist die Leuchte in einem alten Netzwerk eingebunden, kann sie ausgeschaltet durch die Entnahme des Occhio air...
Seite 51
Anschließend auf Gerät click decouple device and entkoppeln klicken und den start the process Vorgang starten 3 Remove the Occhio air mo- 3 Occhio air Modul wie dule as shown and replace abgebildet entnehmen und it immediately gleich wieder einsetzen Geräte in der Nähe /...
Seite 52
All manuals and user guides at all-guides.com...
All manuals and user guides at all-guides.com Steuerung mit dem Occhio air controller (optional) Control using the Occhio air controller (optional) Occhio air controller Occhio air controller Intuitiv bedienbare Fernbedienung Intuitive remote control with four mit vier programmierbaren Tasten programmable buttons (setup via (Einrichtung via Occhio air App).
Seite 55
All manuals and user guides at all-guides.com schalten / switch dimmen / – – – IIII IIII einzelne Leuchten, Gruppen, einzelne Leuchten, Gruppen, oder Szenen schalten oder Szenen dimmen – – – IIII IIII switch individual luminaires, dims individual luminaires, groups or scenes groups or scenes 2700 K...
Seite 56
All manuals and user guides at all-guides.com...
Leuchte nur in abgekühltem Zustand reinigen! Zur Reinigung der Leuchte ein trockenes Mikro- fasertuch verwenden. Detaillierte Pflegehinweise sind unter www.occhio.de/de/company/faq zu finden. Always allow the luminaire to cool down before cleaning! To clean the luminaire, use a dry microfibre cloth. Detailed care instructions are available at www.occhio.de/en/company/faq.
All manuals and user guides at all-guides.com Info & Kontakt Information & contact Weitere Fragen beantwortet gerne Ihr Occhio Fachhändler Your Occhio specialist retailer will gladly answer any other questions www.occhio.de info @ occhio.de...
Zulässige Betriebsbedingung max. 30°C nur im Innenbereich betreiben Prüfzeichen 0,2 m Technische Daten Leuchtmittel Leuchtmittel Occhio »color tune« LED Ausführung LED-board Lebensdauer > 50.000 Std. Energieeffizienzklasse – EEK Entsorgung Bei örtlicher Entsorgungsstelle entsorgen. Mito largo ist recyclebar; RoHS-konform. Nicht in den Hausmüll geben!
Occhio »color tune« LED Version LED-board Lifetime > 50.000 h Energy efficiency class – EEC A + Disposal Dispose of at a local disposal site. Mito largo is recyclable and RoHS compliant. Do not dispose of with the household waste!
