Netti BASIC Montage Seite 5

As soon as the user of the wheelchair sits in the
wheelchair, position the side support in the desired
height and width.
Adjust the angle of the side support on the backrest
tube, by moving the side support horizontal rod
inwards or outwards.
As soon as you have finished the adjustment, tighten
the 2 screws firmly.
The position of the clamp can be secured
with the 2 at the front of the clamp
additional grub screws.
To prevent unauthorized removal of the side
support, you can tighten the screw opposite
of the clamp lever with a 3 mm Allen key.
SIDE SUPPORT BASIC DEPTH ADJUSTMENT:
• Loosen the 2 screws at the back of the side
support pad and move the pad to the desired
depth.
• Tighten the 2 screws firmly.
You can use the side support for Netti round
tube clamp on the left or the right side.
To use the pad for the left or right side, turn the
clamp 180° and mount the clamp lever on top and
the grub screw at the bottom.
Model: Netti Side support BASIC
Version: 2022-02
5
My-Netti.com
