Mounting Instruction - Netti Basic Montage

NETTI SIDE SUPPORT
BASIC
(UK)
Netti side support Basic is especial designed for users
in need for direct support of upper body stability and
position.

1 MOUNTING INSTRUCTION

FOR NETTI SIDE SUPPORT BASIC- FITTING FOR:
NETTI WHEELCHAIRS WITH SQUARE
BACK SUPPORT TUBE
Item number 86145
Netti side support Basic can be adjusted in
height, depth and sidewards.
Before you mount the side support to the wheelchair
you need to define the long lasting seating position
of the user.
• Find the desired position and mark the height at
the back tube where you want to position the side
support.
• Push the clamp over Velcro and back tube.
• It is recommended to position the clamp with the
Italian grip on top as shown in the illustration on
top of this page.
• The 2 screws fixing the clamp to the back tube
should be inserted from the inside.
• Tighten the screws after mounting.
5 mm Allen key
Insert the side support horizontal rod into the fixing
bracket. Fix the side support cushion as far inward as
desired. It is easily adjusted by loosening the Italian
grip and slide the cushion in- or outward.
2
My-Netti.com
Model: Netti Side support BASIC
Version: 2022-02
