2 MOUNTING INSTRUCTION
FOR NETTI SIDE SUPPORT BASIC - FITTING FOR:
NETTI WHEELCHAIRS WITH ROUND BACK
SUPPORT TUBE (NETTI 4U CE )
Item number 86146
Netti side support Basic can be adjusted in height,
depth and side wards.
MOUNTING TO THE BACK
• At the back you will find 2 threaded inserts
underneath the back fabric on each vertical back
tube.
• To mount the star wheels to the back you need to
make 2 holes in the fabric with a screwdriver where
the inserts are.
• Mount the adapter plate with the 2 star wheels at
the back in the holes you just made.
• With the adapter plate you can adjust the side
support sideways.

HEIGHT ADJUSTMENT

• To adjust the side support height you need to use
the vertical adapter.
• Before adjusting the height please define the long
lasting seating position of the user.
• Loosen the 2 screws and adjust the desired height.
• Tighten the screws firmly.
DEPTH ADJUSTMENT:
• You can adjust the side support pad along the
slotted hole on the outside of the side support.
• Loosen the 2 screws and adjust the desired depth.
• Tighten the screws firmly.
5 mm Allen key
Model: Netti Side support BASIC
Version: 2022-02
3
