Programming instructions for the Märklin
A Märklin centre can be used to program all of the CVs but they cannot be read out.
2)
▪ The controller has to be set to "0".
▪ No locomotives are to be on the tracks except the one which is to be programmed!
▪ Please observe the locomotive lighting flashing signals during programming.
▪ Any number of changes/settings can be made as long as the decoder is in programming mode.
1.
Press the STOP and GO buttons at the same time until a reset is carried out
2.
STOP button until deactivation of the track voltage
3.
Enter address 80
4. Press the direction of travel switch and keep it pressed in and then additionally press GO
for at least 0.5 sec in order to reactivate the track voltage
5.
The decoder is in programming mode = slow flashing
6. Enter the register which is to be changed (two figures in the address field)
7.
Confirm by pressing the direction of travel switch = rapid flashing
8. Enter the required value (two figures in the address field)
9.
Confirm by pressing the direction of travel switch = slow flashing
If you wish to program additional CVs, repeat numbers 5.-9.
To stop the programming, switch the centre to "STOP" or enter the address "80" and briefly acti-
vate the direction of travel change.
As a Motorola Digital Centre from Märklin
3)
ween 01 and 80, the value "0" has to be entered via the address as "80".
Programming instructions for the Märklin
▪ No locomotives are to be on the tracks except the one which is to be programmed!
1. Press the ESC button
2.
Select the menu item "New Loc"
3. Select the menu item "Database"
4. Select the article number "36330" with the rotary knob
5.
Press the ESC button
6.
Move to menu option (Change Locomotive") with the knob
7.
Choose menu option ("Address")
8.
Choose menu option ("Name")
Programming with the Märklin
1. Press the "ESC" button
2. Turn the rotary controller to the right until you reach menu item "CHANGE LOC"
3. Turn the rotary controller 2x to the left until you reach menu item "REG"
4. Turn the rotary controller until the required CV address flashes
5. Turn the rotary controller until the required CV value flashes
The decoder confirms the programming with a slight movement at the engine.
Note: You will find additional functions for this decoder at www.zimo.at
8040411920 VI_2013.indd 17
6020/6021
2)
can only be programmed by entering numbers bet-
2)
"Mobile Station" and "Central Station"
2)
Mobile Station:
2)
