CV Name
29 Configuration
register
155 Shunting key
156 Delay deactivation
65 Software-Version
8040411920 VI_2013.indd 15
Description
Diverse locomotive settings, only relevant in DCC
operation. Add the values of each of the functions
to determine the value of the CV29
Bsp.: 28 driving stages + permit analogue
operation = 2+4 = 6.
Bit Function
0 Normal direction of travel
Direction reversal
1 14 driving stages in DCC system
28 / 128 driving stages in DCC
system
2 Deactivate analogue operation
Activate analogue operation
3 RailCom off
1)
RailCom 1) on
4 3-point characteristic line in
accordance with CV2, CV5, CV6
28-point characteristic line in
accordance with CV67 -CV94
5 Use short address (CV1) in DCC
operation
Long address (CV17+18) in DCC
operation
Number of the function key which is used to
decelerate the locomotive speed by half for
the purpose of shunting
Nnumber of the function key which deac-
tivates the delays which are stored in CV3
and CV4
Sub-number of the number of the software
version of the decoder as displayed in CV7
Value Works
Range Value
0 – 255 14
Value
0
1
0
2
0
4
0
8
0
16
0
32
0 – 12 3
0 – 12 4
