Note!
Temperature sensors are being inserted to the Series ICon-TD7000 controller
as follows (through housing via M12 gland entry):
Sensor
Sensor
Version
Type
F
[St-F]
Fe-CuNi
N
[St-n]
NiCr-Ni
acc. to DIN 43710
NiCr-Ni
acc. to DIN IEC 584
P
[St-P]
Pt100
2-wire:
3-wire:
Note:
Pay high attention to the correct setting and use of temperature
sensors
refer to „setting of controller parameters" and "Technical data"!
Installation and Connection
Before initial operation the mains volt-
age supply has to be counterchecked in
accordance to the supply voltage of the
controller (see product label), after that
the
setting
values
set/programmed into the temperature
controller. - refer to „Setting of controller
parameters".
The heating unit and sensor should be
only connected then when all parame-
ters have been checked before and set
correctly.
The required inspections according to
the standards listed under "General
8
Entry 1
Entry 2
+
-
black
-
red
-
green
– no polarity –
white
ie.
ie.
set bridge between 2 and 3
white
ie.
ie.
have
to
be
Entry 3
–
white
green
white
red
red
red
ie.
Safety Instructions" are to be con-
ducted and documented after the
installation of the electric heat instal-
lation or equipment is completed.
Note:
In case of direct entry and connec-
tion of the heating cable or any other
heating device, ensure that the in-
side temperature of the housing
does not exceed a maximum tem-
perature of 70° C (158° F).
In doubt take cold lead-in sleeves
into consideration.
Mantle
colour
black
green
green
– any –
