turck TXF707 Kurz- Betriebsanleitung

TXF707 | TXF710 | TXF715 | TXF721


Mounting
surface

* TXF715/TXF721

8 1
Wall side
Device side
reserved
Technical Data/Certification Data
Approvals and markings
Approvals
For installation in industrial environments:
- emission EN 61000-6-4
- immunity EN 61000-6-2
- radio signals EN 62311, ETSI EN 301 489-1, -3, -17
ETSI EN 300 328 (V2.2.2, BSP ≥ 1.0.707 oder ≥ 1.3.458)
ETSI EN 300 300
cULus cULus (UL File No. E484727)
- UL 61010-1, 3rd Edition and UL 61010-2-201, 2nd Edition
- CAN/CSA C22.2 No. 61010-1, 3rd Edition and
CAN/CSA C22.2 No. 61010-2-201:18
cULus (UL File No. E484803)
Class I, Division 2, Groups A, B, C and D
Technical data
Device
Type, ID TXF707-00VP20
Type, ID TXF710-00VP20
Type, ID TXF715-00VP20
Type, ID TXF721-00VP20
Power supply
Power supply type TXF707/TXF710
TXF715
TXF721
Power consumption TXF707
TXF710
TXF715
TXF721
Battery Yes, rechargeable
System resources
CPU TXF707/TXF710: ARM Cortex-A9, dual core, 800 MHz
TXF715/TXF721: ARM Cortex-A9, quad core , 800 MHz
Operating system Linux RT
Flash TXF707/TXF710: 4 GB
TXF715/TXF721: 8 GB
RAM TXF707/TXF710: 1 GB
TXF715/TXF721: 2 GB
FRAM 64 KB
Real Time Clock, RTC Back-up, Yes
Buzzer
Interface
Ethernet port 1 (RJ45 PoE 10/100 Mbit)
USB ports 1 (Host V2.0, max. 500 mA, available with special cable)
LED 1 (RGB)
Sensors Temperature, 3-axis accelerometer
Wi-fi EEE 802.11a/b/g
(2,4 GHz)
General information
Operating temperature -20...+55 °C (vertical installation)
Storage temperature -30...+80 °C
Relative humidity 5...85 % RH, non condensing
Weight TXF707: 0.7 kg
TXF710: 1.2 kg
TXF715: 4.0 kg
TXF721: 6.0 kg
Protection class IP67 (requires appropriate accessories and cables)
EU Declaration of Conformity
Hiermit erklärt die TURCK GmbH, dass der Funkanlagentyp TXF7... den
Richtlinien 2014/53/EU und 2022/30/EU entspricht. Der vollständige Text der
EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar:
www.turck.com
Le soussigné, TURCK GmbH, déclare que l'équipement radioélectrique du
type TXF7... est conforme aux directives 2014/53/UE et 2022/30/UE. Le texte
complet de la déclaration UE de conformité est disponible à l'adresse internet
suivante:
www.turck.com
Hereby, TURCK GmbH declares that the radio equipment type TXF7... is in
compliance with Directives 2014/53/EU and 2022/30/EU. The full text of the EU
declaration of conformity is available at the following internet address:
www.turck.com
100017841
100017845
100017847
100017849
IEEE 802.3af PoE
IEEE 802.3at PoE+
IEEE 802.3bt 4PPoE
max. 9 W
max. 12 W
max. 19 W
max. 32 W
Radio signal standard/minimum
distance from the body according
to EN 62311
© TURCK GmbH | 100018652 2025-11
