Operating instructions
Safety-monitoring module
Max. switching capacity of the safety contacts:
Switching capacity of the auxiliary contacts:
Protection of the safety contacts:
Fuse rating for the auxiliary contacts:
Utilisation category to EN 60947-5-1:
Dimensions H x W x D:
The data specified in this manual are applicable when the
component is operated with rated operating voltage U

2.5 Safety classification

Standards:
PL:
Control category:
DC:
CCF:
PFH value:
SIL:
Service life:
The PFH value of 2.00 x 10
load (current through enabling contacts) and number of switching
cycles (n ) mentioned in the table below. At 365 operating days per
op/y
year and a 24-hours operation, this results in the below-mentioned
switching cycle times (t
Diverging applications upon request.
Contact load
20 %
40 %
60 %
80 %
100 %
B value (for one channel):
10d
B
10d
MTTF
d
0,1 x n
op
For an average annual demand rate of n
Performance Level PL e can be obtained at maximum load.
n = average number of activations per year
op
d = average number of operating days per year
op
h = average number of operating hours per day
op
t = average demand rate of the safety function in s
cycle
(e.g. 4 × per hour = 1 × per 15 min. = 900 s)
(Specifications can vary depending on the application-specific
parameters hop, dop and tcycle as well as the load.)
MIRO_SAFE+_Switch_H_L_24_en.indd 11
13-14; 23-24; 33-34:
max. 250 V, 8 A ohmic (inductive in case
of suitable protective wiring); min. 10 V / 10 mA;
AC-15: 230 VAC / 6 A; DC-13: 24 VDC / 6 A;
residual current at ambient temperature
up to 45°C: 24 A / 55°C: 18 A / 60°C: 12 A
41-42: 24 VDC / 2 A
external (I
to EN 60947-5-1
Safety fuse 10 A quick blow, 8 A slow blow
external (I
to EN 60947-5-1
Safety fuse 2.5 A quick blow, 2 A slow blow
AC-15: 230 VAC / 6 A
DC-13: 24 VDC / 6 A
100 mm x 22,5 mm x 121 mm
EN ISO 13849-1, IEC 61508, EN 60947-5-1
≤ 2.00 × 10
-8 /h applies to the combinations of contact
) for the relay contacts.
cycle
n t
op/y
525,600 1.0 min
210,240 2.5 min
75,087 7.0 min
30,918 17.0 min
12,223 43.0 min
20%: 20,000,000
40%: 7,500,000
60%: 2,500,000
80%: 1,000,000
100%: 400,000
d x h x 3600 s/h
n op op
op
t
cycle
= 126,720 cycles per year,
op

3. Mounting

3.1 General mounting instructions

Mounting: snaps onto standard DIN rails to EN 60715.
Snap the bottom of the enclosure slightly tilted forwards in the DIN rail
and push up until it latches in position.
= 1000 A)
k

3.2 Dimensions

All measurements in mm.
= 1000 A)
k
Device dimensions (H/W/D): 100 × 22.5 × 121 mm
with plugged-in terminals: 133 × 22.5 × 121 mm

4. Electrical connection

±0%.

4.1 General information for electrical connection

e
As far as the electrical safety is concerned, the protection
against unintentional contact of the connected and therefore
up to e electrically interconnected apparatus and the insulation of the
up to 4 feed cables must be designed for the highest voltage, which
99% (high) can occur in the device.
> 65 points
-8 /h
up to 3 The electrical connection may only be carried out by
20 years authorised personnel in a de-energised condition.
Wiring examples: see appendix

5. Operating principle and settings

5.1 LED functions

• K1: Status channel 1
• K2: Status channel 2
• U : Status operating voltage (LED is on, when the operating voltage
cycle
B
on the terminals A1-A2 is ON)
• U : Status internal operating voltage (LED is on, when the operating
i
voltage on the terminals A1-A2 is ON and the fuse has not been
triggered)

5.2 Description of the terminals

Voltages: A1
A2
Inputs: S11-S12
S21-S22
S21-S22
Outputs: 13-14
23-24
33-34
41-42
Start: S12-X2
S12-X3
EN
MIRO SAFE+ Switch H L 24
Art.-No. 3000-33113-3020012
+24 VDC/24 VAC
0 VDC/24 VAC
Input channel 1 (+)
Input channel 2 (–) (without cross-wire
short detection)
Input channel 2 (–) (with cross-wire
short detection)
First safety enabling circuit
Second safety enabling circuit
Third safety enabling circuit
Auxiliary NC contact as signalling contact
Feedback circuit and
external reset (monitored)
Feedback circuit and automatic start
12.06.2012 09:33:32
11
