7. Dimensions

Cast shaft cover ø700
Class A (like DIN 19596)
air vent /
cable pipe
180°
24 | EngliSH
ø800
Intake
ø1131
90°
screw-connection
BSP 1½"M
max. 1231
270°
Load-distribution plate
ø1700x200
extension
piece
ø588x350
Begu-shaft cover without air vent
Class A, ø785x600x80 or
Class B, ø785x600x125
Max. 3 support rings (DIN 4034-2)
ø785x625x80
Flush cleaning connection
optional vacuum breaker)
Screw-connection
BSP 1½"M
pump 2 ON
pump 1 ON
OFF
0°/
360°
Begu-shaft cover without air vent
Class D, ø785x600x160
Alarm ON
