EN

SAFETY INSTRUCTIONS

SYMBOLS
Read the instructions.
Approved in accordance with
the relevant directives.

TECHNICAL DATA

Size
DESCRIPTION
1. Wall
2. Expander plug
3. Long screw
4. Short screw
5. Screw hook
6. Drum lock
ASSEMBLY
1. Mark out the position of the fastener and
screw the fastener to the wall.
2. Drill the right mounting hole, insert an
expander plug and screw on the line drum
with the long screw. Drill mounting holes
for the line bar at the same height as the
line drum, and insert expander plugs and
screw hooks.
FIG. 1
3. Release the line drum by pulling out the
drum lock from the side. Turn the line
drum clockwise to unwind the lines and
anticlockwise to rewind them. Lock by
pressing the drum lock back in.
FIG. 2
8
4. Pull the line bar out and hook it onto the
screw hooks in the wall opposite the line
drum.
FIG. 3
5. Turn the line drum anticlockwise to stretch
the line, and then press in the drum lock.
After use, release the drum lock, lift off
the line bar from the hooks, and rewind
the lines back into the line drum. Keep
your hands and fingers out of the way –
the automatic rewinding is very quick.
L 14 m
