1 Overview of your C-POWER XS

Thank you!
1 Overview of your C-POWER XS
We thank you for purchasing the C-POWER XS
and for the trust you place in us.
Overview of the scope of delivery (Fig. 1)
1 Button for unlocking the dust bin
2 Exhaust filter
3 Exhaust filter cover
4 Cord retraction button
5 On/Off switch
6 Cleaning indicator
7 Parking bracket
8 Power cord with plug
9 small motor protection filter
10 Dust bin base
11 Emptying button
12 MAX mark
13 Dust bin
14 Cyclone unit
15 Foam plastic element of the dual motor protection filter
16 Filter holder of the dual motor protection filter
17 Dust bin cover
18 Carrying handle
19 Handle
20 Bypass vent
21 Telescopic tube
22 Telescopic tube stop catch
23 Furniture brush
24 Crevice nozzle
25 Release buttons on the suction hose adapter
26 Floor nozzle (illustration serves as an example)
27 "Carpet/hard floor" selector (illustration serves as an example)
28 Parking hook
Operating manual (not shown)
Parquet brush (Fig. 2/2*, optional*)
Turbo brush (Fig. 2/3*, optional*)
Mini turbo brush (Fig. 2/6*, optional*)
* depending on model and scope of delivery

Warranty

The statutory warranty regulations in accordance with the EU Directive
1999/44/EC apply. In non-EU countries the minimum requirements of the
warranty in the respective country apply.
Table of contents
1 Overview of your C-POWER XS .......................................... 13
Technical data ........................................................................ 13
Warranty ................................................................................. 13
2 Safety instructions ............................................................... 14
2.1 About the operating manual ................................................... 14
2.2 Concerning certain groups of persons ................................... 14
2.3 Information on power supply .................................................. 14
2.4 Information on proper use ...................................................... 15
2.5 If the appliance is defective .................................................... 15
2.6 Concerning disposal ............................................................... 15
3 Before use ............................................................................. 16
3.1 Unpacking .............................................................................. 16
3.2 Selecting the proper nozzle .................................................... 16
3.3 Assembly ................................................................................ 16
4 Use ......................................................................................... 17
4.1 Operational safety .................................................................. 17
4.2 How to vacuum ...................................................................... 17
4.3 Switching off ........................................................................... 17
4.4 Transport and storage ............................................................ 17
5 Maintenance ......................................................................... 18
5.1 Emptying the dust bin module ................................................ 18
5.2 Cleaning dust bin and motor protection filter .......................... 18
5.3 Cleaning the exhaust filter ...................................................... 19
5.4 Spare parts and accessories .................................................. 19
5.5 Before you send in the appliance ........................................... 19

Technical data

Type of appliance : bagless cylinder vacuum cleaner
: C-POWER XS
Model name
Model number : M2815 (-0/-1.../-8/-9)
Voltage : 220 - 240V ~, 50 Hz
Power : 800 W
Dust bin capacity : max. capacity: approx. 1.8 litres
Power cord length : approx. 5 m
Weight : approx. 4 kg
Designation :
We reserve the right to make changes to technical and design specifications in the in-
terest of continuous product improvement. © Royal Appliance International GmbH
13
