2. Designations
2.3 Designation of current injection (Classic and Premium version)
Antenna connection
Power indicator LED
2.4 Designation of control unit (Professional version)
LCD display
Connection
Set-top box
Warning: Connect the device only at a 5 amp protected line.
The line must be at least 2.5 mm² strong. (never directly to the car battery).
On / Off switch
„Up" button „Down" button
SETTOP
Connection
Antanna
UP DOWN SET
ANT DATA
Connection
Service
ENGLISH
Set-top box
connection
DC power supply
Power switch
Confirm button
DC12-24 V
Power supply
