How to Estimate the Battery SOC?

The SOC values listed below are estimated based on the resting voltage (open-circuit voltage at rest)
when the battery is at rest for 30 minutes, not in charging or discharging state.
SOC
100%
99%
90%
70%
40%
The table above is for reference only because slight variations in battery voltage may occur
among different batteries.

Battery Management System

This smart battery management system has more than 60 fault alarms and protections to fully
protect your battery safety. Below we list some common faults and protections for reference.
Battery Operating Status
Battery Cell Overvoltage
Battery Cell Undervoltage
Cell Undervoltage Permanent
Failure
Charge High Temperature
Discharge High Temperature
Charge Low Temperature
Discharge Low Temperature
Open Circult Voltage
13.6V
13.4V
13.2V
13.1V
13.0V
Trigger
Protection
Recover
Trigger
Protection
Recover
Protection Trigger
Trigger
Protection
Recover
Trigger
Protection
Recover
Trigger
Protection
Recover
Trigger
Protection
Recover
EN
— 22 —
SOC Open Circult Voltage
30%
20%
14%
9%
0%
Condition (For Reference Only)
Battery Cell Voltage ≥ 3.65V
Battery Cell Voltage ≤ 3.45V
Battery Cell Voltage ≤ 2.7V (> 0°C)
Battery Cell Voltage ≤ 2.2V (≤ 0°C)
Charge Current ≥ 0.5A
Battery Cell Voltage ≤ 1.5V
Battery Temperature ≥ 131°F (55°C)
Battery Temperature ≤ 122°F (50°C)
Battery Temperature ≥ 140°F (60°C)
Battery Temperature ≤ 122°F (50°C)
Battery Temperature ≤ 32°F (0°C)
Battery Temperature ≥ 37°F (3°C)
Battery Temperature ≤ -4°F (-20°C)
Battery Temperature ≥ 1.4°F (-17°C)
12.9V
12.8V
12.7V
12.6V
10.8V
