REVOX AUTOLOCATOR
C.SERIE5 STUDEFI FIÄ/OX
13.03
.
90
REVOX
ELA
AG,
CH-8105
REGENSDORF
STORE
U7l
If
STORE
is
pressed,
followed bya
memorylocation number
(1...9, -1...9), A-LOC
or
ROLLBACK(onC274
and,C278 also COUNTER,
TIME, DATE
or
CODE
in
C-
TRACK
mode),
the value shown on the display is stored
in
the corresponding
memory location.
Storabl
e
ranges:
Memory
location:
-9.59.59 <-=>
59.59.59
ROLLBACK :
00.00.00
<==>
00.00.59
COUNTER :
-9.59.59
<==>
59.59.59
TIME
:
00.00.00
<==>
23.59.59
DATE
:
01.01.01
<==>
31.12.99
C0DE
:
00.00.00
<==>
99.99.99
RECALL t18l
If
RECALL
is
pressed
followed by
a
memorylocation number (0...9 or -0..-9),
A-
LOC
or ROLLBACK
the
stored
value
will
be
displayed
for approx. 2
seconds.
Also used
for
extended
function inquiry
with
the keys
<
<
and
>
>.
See
speciai
functions.
SEARCH t19l
Positions the tape
on
the
address
shown
on
the display. The address
is
not
stored.
If
C-TRACKis enabled
on
theC274andC278,
a
tape
address can also be
searched
based
on the recorded data
code.
RESET
t20l
The
tape counter reading
is reset to zero.
All
LOC
addresses
are
recalculated
so
that the physical
address is
not
changed.
IMPORTAI{T:
ARESET
on
the
machine itself
is
notprocessed
bythe autolocator.
This
means
that the
LOC
addresses
will
not
be
recalculated!
DISPLAY l21l
6-Position 7-segment LED display
for showing the counter real-time
counter
reading
or the time/date,/code of the data recording.
l22l
2-Position
7-segment LED
displayfor showing
the
locator memory number
0...9
or
-0...9.
READYCH1...8
[23]
Readies
channels 1...8
for recording
(C27O
only channels
1*2,
C274
only
channels
1...4,
the other
ready keys
are
inoperative
on these
machines), the red
LED above the key
flashes.
While
a
recording
is
in
progress the
LED
is
continually
lit.
INPUT
CH1./2
t24l
Switches
the audio to input.
REPRO
and SYNC are cancelled. On
the
C270
channels
'1.
+ 2
can be
switched
individually,
on
the
C274 and C278 all
channels
are
switched
concurrently (operable via CH1 and CH2).
SYNC
CH1/2
l25l
Switches
to reproduce from record
head.
INPUT and
REPRO
are cancelled.
In
REC
mode the
corresponding
channels
are
automatically switched
to
INPUT.
On
the
C27O
channels 1
+
2 can
be
switched
individually,
on
the C274 and C278
all
channels
are
switched
concurrently (operable via CH1 and CH2).
REPRO
C}i,7/2
t26l
Switches
audio
to
REPRO.
INPUT and SYNC are cancelled.
On
the
C27O
the
channels L
+
2
can
be
switched
individually,
on the
C274 andC278
aII
channels
are
switched
concurrently (operable via CHL or CH2).
0...9
t27l
The
numeric
keys can
be
used
for entering
addresses
into the display [21].
The
digits
appear
from left to
right
and
remain
on
the display
for approx.
8
seconds
(unless cancelled by
a
function key).
