Danfoss RSA Installationsanleitung Seite 2

Installation Guide, RSA
DK
Fyringsgasolie
6 mm /s (cSt)
2
* Dysekapacitet
p > 0 bar (x 10 2 kPa)
p > 0.35 bar (x 10 2 kPa)
1400 min.
-1
2 | © Danfoss | 2019.08
GB
Fuel gas oil Heizöl
6 mm /s (cSt) 6 mm
2
* Nozzle capacity * Düsenleistung
H Ø4 Ø5
m mm mm
4.0 51 100
3.5 45 100
3.0 38 94
2.5 32 78
2.0 26 62
1.5 19 47
1.0 13 31
0.5 6 16
* 2.5 kg/h
H Ø4 Ø5
m mm mm
4.0 100 100
3.5 95 100
3.0 89 100
2.5 83 100
2.0 77 100
1.5 71 100
1.0 64 100
0.5 58 100
* 2.5 kg/h
H Ø4 Ø5
m mm mm
0.0 52 100
-0.5 46 100
-1.0 40 97
-1.5 33 81
-2.0 27 66
-2.5 21 51
-3.0 15 36
-3.5 9 21
-4.0 2 6
* 2.5 kg/h
RSA 40
H Ø6 Ø8 Ø10
m mm mm mm
4.0 34 100 100
3.5 32 100 100
3.0 30 94 100
2.5 28 85 100
2.0 26 81 100
1.5 24 75 100
1.0 22 68 100
0.5 19 62 100
0.0 17 55 100
-0.5 15 48 100
-1.0 13 42 100
-1.5 11 35 86
-2.0 9 29 70
-2.5 7 22 54
-3.0 5 16 38
-3.5 3 9 22
-4.0 1 3 6
DE FR
Fioul
/s (cSt) 6 mm /s (cSt)
2 2
* Débit du gicleur
Ø6 Ø4 Ø5
mm mm mm mm
100 26 62
100 22 55
100 19 47
100 16 39
100 13 31
97 10 23
65 6 16
32 3 8
5.0 kg/h
Ø6 Ø4 Ø5
mm mm mm mm
100 51 100
100 48 100
100 45 100
100 41 100
100 38 94
100 35 86
100 32 79
100 29 71
5.0 kg/h
Ø6 Ø4 Ø5
mm mm mm mm
100 26 63
100 23 56
100 20 48
100 17 41
100 14 33
100 10 26
75 7 18
44 4 11
12 1 3
5.0 kg/h
RSA 60
Ø12 Ø8 Ø10 Ø12 Ø15
mm mm mm mm mm
100 23 71 100 100
100 21 67 100 100
100 20 62 100 100
100 18 58 100 100
100 17 54 100 100
100 16 49 100 100
100 14 45 100 100
100 13 41 99 100
100 12 36 89 100
100 10 32 78 100
100 9 28 68 100
100 7 23 57 100
100 6 19 47
100 5 15 36
79 3 10 25
46 2 6 15
13 1 2 4
SE
Eldningsolja
6 mm /s (cSt)
2
* Munstyckskapacitet
Ø6 Ø 5 Ø6 Ø8
mm mm mm
100 31 65 100
100 27 57 100
97 23 49 100
81 20 40 100
65 16 32 100
49 12 24 77
32 8 16 51
16 4 8 26
10.0 kg/h
Ø6 Ø 5 Ø6 Ø8
mm mm mm
100 62 100 100
100 58 100 100
100 54 100 100
100 51 100 100
100 47 97 100
100 43 89 100
100 39 81 100
100 35 73 100
10.0 kg/h
Ø6 Ø 5 Ø6 Ø8
mm mm mm
100 32 66 100
100 28 58 100
100 24 50 100
84 20 42 100
69 17 34 100
53 13 27 84
37 9 19 59
22 5 11 35
6 1 3 10
10.0 kg/h
RSA 95
Ø8 Ø10 Ø12 Ø15
mm mm mm mm
44 100 100 100
41 100 100 100
38 93 100 100
36 87 100 100
33 80 100 100
30 74 100 100
28 67 100 100
25 61 100 100
22 54 100 100
20 48 99 100
17 41 86 100
14 35 73 100
96 12 29 59 100
75 9 22 46 100
53 6 16 32 79
31 4 9 19 46
9 1 3 5 13
NL
Huisbrandolie
6 mm /s (cSt)
2
* Verstuiverkapaciteit
Ø6 Ø8 Ø10
mm mm mm
31 99 100
27 87 100
23 74 100
20 62 100
16 49 100
12 37 91
8 25 60
4 12 30
20.0 kg/h
Ø6 Ø8 Ø10
mm mm mm
65 100 100
61 100 100
57 100 100
53 100 100
49 100 100
45 100 100
41 100 100
37 100 100
20.0 kg/h
Ø6 Ø8 Ø10
mm mm mm
33 100 100
29 93 100
25 80 100
22 68 100
18 56 100
14 43 100
10 31 75
6 19 45
2 6 15
20.0 kg/h
RSA 125
Ø8 Ø10 Ø12 Ø15
mm mm mm mm
33 81 100 100
31 76 100 100
29 71 100 100
27 66 100 100
25 61 100 100
23 56 100 100
21 51 100 100
19 46 96 100
17 41 86 100
15 36 76 100
13 32 65 100
11 27 55 100
9 22 45 100
7 17 35 85
5 12 24 60
3 7 14 35
1 2 4 10
BI.DF.V4.55
