DESCRIPTION OF THE APPLIANCE
- (Fig. 6)
1. Dust and/or water container
2. Pivoting wheels
3. Hose inlet
4. ON/OFF switch
5. AUTO switch automatic simultaneous ignition
switch for power tools (depending on the model)
6. Socket panel for connection to power tools (depen-
ding on the model)
7. Clasp to open dust collection compartment
8. Lid
9. Handle
10. Air outlet grid
11. Power supply cable
12. Spline
13. Guides
(A). Single or double layer paper bag
(B). Paper cartridge filter
(C). Filter in polyurethane foam
(only for wet & dry models)
(D). Basket with safety float
(only for wet & dry models)
(E). Outlet filter of motor cooling air
(only for wet & dry models)
(F). Air outlet filter (according different models)

ACCESSORIES PROVIDED

(according different models)*: optional (see Fig. 5)
A1 Hose complete with handle and connection
B1 extension tubes in metal or plastic B metal
telescopic tube
C1 Crevice tool
D1 Upholstery nozzle
E1 Dual-purpose brush or multi-purpose brush with
accessory for hard-floors and water.

ASSEMBLY INSTRUCTION

Before using the appliance always check that all the
filters provided are in the correct position.
Position the polyurethane filter around basket (D)
(Fig. 7, position 1).
Position cartridge filter (B) in its seat (Fig. 7, position
2-3).
When using bag (A), make sure the bag's flange is
properly inserted into the appropriate grooves 13 in the
dust and/or water container (Fig. 7, position 4).
Arm vibrations
a <= 2,5 m/s
h
sound pressure level : LpA = 79 dB (A)
K
pA =
2
1 dB (A)
EN - T35
Insert the bayonet cap at the end of the flexible hose
into the inlet 3 and turn clockwise until locked as shown
in Fig. 2.
Join the extension tubes together or adjust the length
of the telescopic tube by using the release button, and
then connect the tubes or tube to the handle on the
hose applying light pressure.
To the other end attach a suitable accessory: Fig. 5:
The dual-purpose brush cleans hard floors, carpets and
textile surfaces. To extract or remove the bristle strip
push the button on the brush.
The multi-purpose brush provided is suitable for
cleaning carpets and textile surfaces.
To clean hard surfaces and for vacuuming water it is
necessary to attach the provided insert into the brush
head.
To fit the inserts, gently push the accessory into the
main brush head until the hooks click into the side slots
on the brush head as shown in Fig. 3.
All the accessories provided can be attached to the end
of the tubes or directly to the handle.

INTENDED USE

• This machine is intended for collection, extracting,
conveying and separation of nonflammable dry dusts
and non-flammable liquids and water-air mixtures.
• This M class dust extractor is for professional use
and is suited for trades and workshops.
• According to IEC/EN 60335-2-69, vacuum of dust
category M may only be used for vacuuming and
extraction of hazardous dusts with an exposition limit
value ≥ 0,1 mg/m
3
• This appliance is suitable for commercial use, for
example in hotels, schools, hospitals, factories,
shops, offices and rental bussinesses.
• The appliance is intended for use as a wet and dry
dust extractor.
• Failure to comply with the abovementioned
conditions will lead to cancellation of the guarantee.
Restriction of use
DO NOT use the dust extractor for combustible dust.
DO NOT use the dust extractor in explosive
atmospheres.
SYMBOLS
CAUTION! It is important to be careful on
safety grounds.
IMPORTANT
LOCKED
OPEN
