Double spotlight 2x50W SMD LED 2X4250lm on stand 1.8m
NOTE: READ THIS MANUAL CAREFULLY BEFORE USING THE
POWER TOOL AND KEEP IT FOR FUTURE REFERENCE.
SPECIFIC SAFETY PROVISIONS
• Before installing the device, make sure that no current is flowing in
the mains.
• The following instructions should be read in full before installation.
• If the cover is damaged, it must be replaced with toughened glass
as soon as possible.
• Do not use if the cable is found to be cut or damaged.
• Ensure that the mains voltage corresponds to the rated voltage of
the appliance.
• Replacement of a component or repair should be carried out by
persons authorised to do so.
• Use only within the permitted temperature range of -25°C to 45°C.
• The unit reaches high temperatures during operation. Installation on
flammable surfaces not permitted.
• The device should be at least 1 metre away from other objects.
• It is not permitted to dismantle the floodlight yourself.
DESCRIPTION OF THE PICTOGRAMS USED
1 2
1.Read the operating instructions
2.The product meets the requirements of EU directives
3.The product meets the requirements of the Eurasian Customs Union
4.The product meets the requirements of the national quality assessment
system in Ukraine
5.Protection class IP65
DESCRIPTION OF THE GRAPHIC ELEMENTS
Fig. B.
1.Lamp
2.Fastening bolt
3.Length lock knobs
4.Fastening screws
5.Tripod
OPERATION OF THE DEVICE
• Extend the tripod legs as far as they will go.
• Lock the leg positions with the knob (fig. B-4).
• Extend the tripod to the desired height by unscrewing the knobs
(Fig. B-3) and extending. Turn the knobs to lock the tripod at the
selected height.
• Screw the frame to the tripod with a screw.
• Screw the lamps to the frame using screws.
• Adjust the inclination of the lamp by loosening the side screws
connecting the lamp to the frame.
• Connect the lamp to the power source.

TECHNICAL DATA

SMD double reflector
Parameter
Supply voltage
Power
Number of diodes
Type of diode
Colour temperature
Luminous flux
IP degree of protection
Protection class
Mass
ENVIRONMENTAL PROTECTION
Electrically-powered products should not be disposed of with
household waste, but should be taken to appropriate facilities for
disposal. Contact your product dealer or local authority for information
on disposal. Waste electrical and electronic equipment contains
substances that are not environmentally friendly. Unrecycled
equipment poses a potential risk to the environment and human
health.
"GTX Poland Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "GTX Poland ") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including among
99-062
3 4
Value
230V AC 50Hz
2 x 50 W
2 x 50
LED
6500K
2x4250 lm
IP65
I
4.19 kg
others. All copyrights to the contents of this Manual (hereinafter referred to as "Manual"),
including but not limited to its text, photographs, diagrams, drawings, as well as its
composition, belong exclusively to GTX Poland and are subject to legal protection
pursuant to the Act of February 4, 1994 on Copyright and Related Rights (i.e. Journal of
Laws 2006 No. 90 Item 631 as amended). Copying, processing, publishing, modifying for
commercial purposes the entire Manual as well as its individual elements without the
written consent of GTX Poland is strictly prohibited and may result in civil and criminal
liability.
EU Declaration of Conformity
Manufacturer: GTX Poland Sp. z o.o. Sp.k., 2/4 Pograniczna St. 02-285
Warsaw
Product: Double reflector
Model: 99-062
Trade name: NEO TOOLS
Serial number: 00001 ÷ 99999
This declaration of conformity is issued under the sole responsibility of the
manufacturer.
The product described above complies with the following documents:
Low Voltage Directive 2014/35/EU
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
Regulation (EU) 2019/2020 implementing Directive 2009/125/EC
Regulation (EU) 2019/2015
And meets the requirements of the standards:
EN 60598-2-5:2015; EN 60598-1:2015+A1:2018; EN 62471:2008; EN
62493:2015; EN 62031:2008+A1:2013+A2:2015;
5
EN IEC 55015:2019; EN IEC 61000-3-2:2019; EN 61000-3-
3:2013+A1:2019; EN 61547:2009;
IEC 62321-3-1:2013; IEC 62321-5:2013 IEC 62321-4:2013+AMD1:2017
CSV;
IEC 62321-6:2015; IEC 62321-7-1:2015; IEC 62321-7-2:2017; IEC
62321-8:2017
This declaration relates only to the machinery as placed on the market and
does not include components
added by the end user or carried out by him/her subsequently.
Name and address of the EU resident person authorised to prepare the
technical dossier:
Signed on behalf of:
GTX Poland Sp. z o.o. Sp.k.
2/4 Pograniczna Street
02-285 Warsaw
Paweł Kowalski
GTX Poland quality officer
Warsaw, 2022-02-01
Подвійний прожектор 2х50Вт SMD LED 2X4250lm на підставці
ПРИМІТКА: УВАЖНО ПРОЧИТАЙТЕ ЦЕЙ ПОСІБНИК ПЕРЕД
ВИКОРИСТАННЯМ ЕЛЕКТРОІНСТРУМЕНТУ ТА ЗБЕРЕЖІТЬ ЙОГО
ДЛЯ ПОДАЛЬШОГО ВИКОРИСТАННЯ.
КОНКРЕТНІ ЗАХОДИ БЕЗПЕКИ
• Перед
встановленням
електромережі немає струму.
• Перед установкою слід повністю прочитати наступні інструкції.
• Якщо кришка пошкоджена, її необхідно якомога швидше
замінити на загартоване скло.
• Не використовуйте, якщо кабель перерізаний або пошкоджений.
• Переконайтеся, що напруга в мережі відповідає номінальній
напрузі приладу.
• Заміна
компонента
уповноваженими на це особами.
• Використовуйте тільки в допустимому діапазоні температур від
-25°C до 45°C.
• Під
час
Встановлення на легкозаймистих поверхнях не допускається.
• Пристрій повинен знаходитися на відстані не менше 1 метра від
інших об'єктів.
• Самостійно демонтувати прожектор заборонено.
4
(UA)
ПЕРЕКЛАД ОРИГІНАЛЬНОЇ ІНСТРУКЦІЇ
1,8м
99-062
пристрою
або ремонт
роботи пристрій досягає
переконайтеся, що в
повинні виконуватися
високих температур.
