First Degree Fitness E350 Bedienungsanleitung Seite 53

Replacing the Rower Bungee Shock Cord
10. Upper rear right to lower rear right
and left rear Pulleys.
11. Lower left rear to upper left rear
Pulley.
12. Upper left rear Pulley to tie off point.
Finish the Bungee rewrap by tying
off the Bungee. You may elect to
not use a tie wrap as the metal tab
is designed as a stand alone
attachment point. Thread the
Bungee through to desired tension
and thread the Bungee end through
the upper hole as shown.
13. Reattach the C-Clip, Magnetic Ring
and Rear Main Shaft Bolt. Tighten
securely.
Finally, reattach the Sensor Lead and
replace the Perspex rear cover.
25
C Clip
