2.1.5 Backlight indicator
− Backlight mode of EOX
Backlight mode
disabled
− With integrated ambient light sensor EOX
disables backlight mode in bright conditions.
− Once backlight mode is enabled backlight is turned on for 2s with each button press.
− If backlight is off, first button press only turns backlight on and does not trigger any other action.
Backlight mode
enabled and backlight
OFF
2.1.6 Speed
− Current speed of E-System is permanently shown in EOX
− Speed unit (kmh or mph) depends on device settings (see chapter 3.5)
Current Speed
® VIEW 1300 is indicated in segment area.
Backlight mode
enabled
VIEW 1300 automatically enables backlight mode in dark conditions and
®
3 s w itho u t b utt on p re s s
A | | B | | C
enabled and backlight
Backlight mode
ON
® VIEW 1300 segment area
EOX
C o n tr ol
A | | B| | C
E O X V IE W 13 0 0
®
® VIEW 1300 I Segmented display area I 41
