DistanceMaster Compact Plus 50
The range is set to a maximum distance of 10 m from the terminal
device and greatly depends on the ambient conditions such as the
thickness and composition of walls, sources of interference as well
as the transmit / receive properties of the terminal device.

Application (app)

An app is required to use the digital connection. You can download the
app from the corresponding stores for the specific type of terminal device:
!
Make sure that the wireless interface of the mobile device
is activated.
After starting the app and activating the digital connection, a connection
can be set up between a mobile device and the measuring device.
If the app detects several active measuring devices, select the matching
device.
This measuring device can be connected automatically the next time
it is switched on.

Error codes:

Err101: Replace the battery
Err154: Outside the measuring range
Err156: Received signal too weak
Err194: Value outside display range

Important notices

– The laser points to the location that will be measured.
No objects may get into the laser's line of measurement.
– The device compensates the measurement for different room
temperatures. Therefore allow the device a brief adaptation period
when changing locations with large temperature differences.
– The device is only conditionally useable in outdoor areas and cannot
be used in strong sunlight.
– The measurement results of outdoor measurements may be influenced
or falsified by rain, fog and snow.
– In unfavourable conditions, e.g. with poorly reflecting surfaces, the
maximum deviation may be greater than 3 mm.
– Carpeting, upholstery or curtains will not reflect the laser optimally.
Measure to flat surfaces.
– Measurements made through glass (window panes) can falsify
measurement results.
– An energy-saving function switches the device off automatically.
– Clean with a soft cloth. Water may not be allowed to penetrate
the housing.
13
EN
