Installation instructions, only for experts
Time
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Timer operating mode I/0 (On/Off): in the On/Off operating mode, the controller
switches off after the set On-time has elapsed and is not activated again.
Gesamtlaufzeit (siehe 6.3 Laufzeit)
EIN
Ein-Zeit
AUS
Fig. 16: Timer I/0 operating mode
Function selection switch
6 5
OFF OFF
OFF OFF
OFF OFF
OFF OFF
OFF ON
OFF ON
OFF ON
OFF ON
ON OFF
ON OFF
ON OFF
ON OFF
ON ON
ON ON
ON ON
ON ON
p. 25/32
4 3
OFF OFF
OFF ON
ON OFF
ON ON
OFF OFF
OFF ON
ON OFF
ON ON
OFF OFF
OFF ON
ON OFF
ON ON
OFF OFF
OFF ON
ON OFF
ON ON
