Pyrolino
| Children's wheelchair
Journeys outside the residence should only be carried out with sufficient
driving experience. If possible, someone should accompany the child.
To make it easier to negotiate obstacles, the companion must position
the wheelchair at a right angle to the obstacle by pressing the tip assist
with the foot.
According to the German traffic regulations (STVZO) dated 1/1/1981,
manually operated wheelchairs travelling on public roads (including
pavements) must have permanently attached illumination.
This consists of (passive):
two red reflectors in the back
two yellow reflectors on the side (on both sides).
60
All manuals and user guides at all-guides.com
6. Technical data
Dimensions
Total length with leg rests:
Overall width:
Height:
Folded (WxHxL):
Lower leg length, standard:
Lower leg length optional:
Seat witdh:
Seat deapth:
Seat height (basic setting):
Seat angle (basic setting): :
Backrest angle:
Backrest height::
Distance of armrest to seat
surface:
Length of the armrest
measured from the backrest:
Horizontal position
of rear axle, measured
from the backrest:
Bischoff & Bischoff GmbH | 01.06.2019
Pyrolino
Children's wheelchair |
915 mm
540 mm
825 - 955
320 x 825 x 955 mm
280 - 360 mm without seat
cushion
340 - 420 mm with seat cushion
420-480 mm
330 / 350 mm
370 mm
440 mm
490 mm with seat cushion
90°
420 mm
165-235 mm with seat cushion
260 mm
-15 mm
61
