FOLDING GAZEBO
˜Introduction
We congratulate you on the
purchase of your new
product . You have chosen a high
quality product . Familiarise yourself
with the product before using it for
the first time . In addition, please
carefully refer to the operating
instructions and the safety advice
below . Only use the product as
instructed and only for the
indicated field of application . Keep
these instructions in a safe place . If
you pass the product on to anyone
else, please ensure that you also
pass on all the documentation with
it .
˜Proper use
The product is designed as a view
and sun protection in outdoor
areas . It is not intended for
permanent out-door use as it is
only weather resistant to a limited
extent . The product is not intended
for commercial use .
˜Description of parts
Pavilion roof
[ 1 ]
Corner joint with button
[ 2 ]
Tent peg
3 ] [
Base plate
4 ] [
Guy line
5 ] [
Corner tarp
[ 6 ]
Hook for corner tarp
[ 7 ]
V-tent pegs
8 ] [
Side wall without window
9 ] [
Extending foot
10 ] [
Side wall with window
[ 11 ]
Side wall and roof hook and
12 ] [
loop fasteners
Loop for guy line
[ 13 ]
Crossbars
[ 14 ]
Corner bars/telescoping bars
[ 15 ]
Roof bars
16 ] [
Ceiling hook (max . load
[ 17 ]
2 .5 kg)
˜Technical data
Dimensions: approx . 300 x
260 x 300 cm
(L x H x W)
˜Scope of delivery
1 Pavillion
1 Storage bag
1 Assembly instructions
