User manual / Bedienungsanleitung
4. I nstallation on other turntables
I f your turntable does not have a replaceable tonearm base, we recommed to contact the
manfucaturer of the turntable, in order to get your turntable professionally prepared for the
Clearaudio swing base
5. Troubleshooting
First check the possible causes to rule out incorrect operation if you have a problem with your
base
. Please contact your dealer if the error persists!
Never try to open the unit and/ or repair it yourself, this w ill void the w arranty!
Error
Sw ing function
w ithout limitation.
Tonearm height
changes during use.
Tonearm w ill not
sw ing into desired
direction.
Tonearm foot does
not fit into the
sw ing
base
.
6. Technical details
Material:
Weight:
Outer diameter:
I nner diameter:
Height:
Made in Germany
.
Cause
The clamping of the tonearm
base is too loose.
The clamping of the tonearm
base is too loose.
swing base
The was installed
incorrectly.
The clamping srew has already
been screwed in too far.
Aluminium
136g
59mm
24.85mm
26mm
Measure
swing base
Check and adjust the
swing base
Check and adjust the
swing base
Reassemble the
to the instructions.
Loosen the screw to insert the tonearm.
swing
if necessary.
if necessary.
again according
