grid's fixing element.
5.
Tighten the blade-fixing element by screwing it clockwise to the shaft.
6.
Fix the safety grille into position by replacing the locking nut tightly by hand. Do not force
the locking nut.
The groove in the centre of the fan blade aligns with a T-bar on the motor shaft to ensure it is
installed correctly.
Fix the blades by screwing the fixing element anti-clockwise at the end of the motor's shaft.
The spinner is self-tightening; do not force it.
Put the rear grid (6) together with grid fastening ring (7), and use screw to fasten it.
Grid-fixing
element.
TIghten the fixing element anti-clockwise.
FORCESILENCIE 690 FRESHESSENCE
ENGLISH
17
