CSL TitanBox Bedienungsanleitung Seite 27

CPU • Intel Core i9 12900H, 14 cores (8 E-cores + 6 P-cores), 20 threads
RAM • 2x DDR5 SO-DIMM up to 4800MHz (max. 96GB)
Hard disks
•
•
•
Graphic
• Intel Iris Xe Graphics with 96EU up to 1.45 GHz
Audio
•
•
Connections
•
•
•
•
•
•
•
•
•
Wi-Fi •
•
Network •
•
Input
• External 179.9W Watt power supply 19V / 9.47A
Dimensions
• 189 x 186 x 48 mm
English
E-cores: Turbo Boost up to 3800 MHz
P-cores: Turbo Boost up to 5000 MHz
(Basic equipment depends on the model)
1x M.2 PCIe 4.0 NVMe SSD 2280 (Alt U.2)
1x M.2 PCIe 3.0 NVMe SSD 2280/22110
1x M.2 PCIe 3.0 NVMe SSD 2280/22110
(Basic equipment depends on the model)
Integrated OnBoard Controller 5.1 HD audio via HDMI
Stereo via 3.5 mm jack (Realtek ALC269)
1x USB 3.2 Gen1 Type-A
2x USB 3.2 Gen2 Type-A
2x USB 4 Type-C
2x USB 2.0 Type-A
1x Headphone/microphone connection
2x 10G SFP+
2x 2,5G Ethernet RJ45
1x HDMI 2.0
1x DC round plug socket
Mediatek/AMD RZ616 AX2400, Wi-Fi 6E 802.11 ax (2x2)
WLAN, 2.4 GHz & 5 GHz & 6 GHz Tri-Band
Bluetooth® 5.2
2x SFP+(Intel Ethernet port X710 with 10Gbit/s)
2x Ethernet RJ45 (Intel Ethernet controller i226-V / i226-LM
with 2.5Gbit/s)
Length Width Height
27
