Baumer VAX Betriebsanleitung Seite 37

Baumer
NVIDIA
Kamera Typ
Monochrom
VAX(.2)-50M.I.NVX
Farbe
VAX(.2)-50C.I.NVX
VAX-50C.I.NX16
V1.3 | VAX(.2) Smart Cameras
®
Jetson Xavier NX™
Line 1
Line 1
current limiter
cable termination
Line 2
internal GPIO
(Output)
300
Ω
CPU
CPU
internal GPIO
(Input)
300
Ω
CPU
CPU
internal GPIO
(Output)
300
Ω
CPU
CPU
UART
UART
internal GPIO
(HWPWM1)
300
Ω
CPU
CPU
internal GPIO
(HWPWM2)
300
Ω
CPU
CPU
internal GPIO
(HWPWM3)
300
Ω
CPU
CPU
internal GPIO
(HW PWM4)
300
Ω
CPU
CPU
System on Modul (SoM)
NVIDIA® Jetson Xavier NX™
NVIDIA® Jetson Xavier NX™
NVIDIA® Jetson Xavier NX™
≥ 1
RS232 Driver
PWM Driver
EN
PWM
EN
PWM
EN
PWM
EN
PWM
Betriebsanleitung
Elektrische Installation
Power Vcc
Pin 1
12V (- 20 %) ... 24 V (+ 20 %)
Pin 2
GND (Power)
I
IN
IN 1
Pin 3
I
IN
IN 2
Pin 5
Pin 8
RS232 TxD
RS232 RxD
Pin 10
Power (IO)
Pin 12
12 V (- 20 %) ... 48 V (+ 10 %)
I
OUT
Pin 4
Out 1
R
L
I
OUT
Pin 6
Out 2
R
L
I
OUT
Pin 7
Out 3
R
L
I
OUT
Pin 9
Out 4
R
L
Pin 11
GND (IO)
| 7
37
