Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2
Product description (Fig. 1-22)
1.
Steering
2.
Drive bow
3.
Engine brake lever
4.
Upper push bar
5.
Quick clamp lever
6.
Plastic star grip nut
7.
Cable clip
8.
Lower push bar
9.
Guide plate (lower push bar)
10.
Fuel filler cap
11.
Fuel tank
12.
Air filter cover
12a. Air filter
13.
Fuel valve
14.
Water connection
15.
Idler
16.
Spark plug connector
16a. Spark plug
17.
Exhaust pipe
18.
Oil dipstick
19.
Side discharge flap
19a. Side discharge
20.
Cutting height adjustment
21.
Drive wheel
22.
Discharge flap
23.
Grass collection basket
23a. Grass collection basket fill level indicator
24.
Rope hook
25.
Pull starter
26.
Mulching insert
27.
Blade
28.
Blade screw
29.
Washer
30.
Engine spindle
31.
Carburettor screw
32.
V-belt
3
Scope of delivery (Fig. 1-2)
Item QuantityDesignation
4.
1 x
5.
2 x
6.
4 x
7.
1 x
8.
1 x
19a.
1 x
23.
1 x
26.
1 x
A.
2 x
B.
2 x
C.
2 x
D.
4 x
E.
2 x
1 x
4
Proper use
The petrol lawnmower is intended for private use i.e. for
use in home and gardening environments. Private use of
the lawnmower refers an annual operating time generally
not exceeding that of 50 hours, during which time the ma-
chine is primarily used to maintain small-scale, residential
lawns and home/hobby gardens. Public facilities, sporting
halls, and agricultural/forestry applications are excluded.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Due to physical danger to the user, the lawnmower must
not be used for the following work (incomplete list):
• for trimming bushes, hedges and shrubs,
• for cutting climbing plants,
• for lawn care on roof plantings and in balcony boxes,
• for chipping and shredding tree and hedge cuttings,
• for cleaning pavements (vacuuming, blowing away),
• for levelling ground elevations, such as molehills.
• for transporting cuttings, except in the grass collection
basket provided.
www.scheppach.com
Petrol lawnmower with upper push bar
Quick clamp lever
Plastic star grip nut
Cable clip
Lower push bar
Side discharge
Grass collection basket
Mulching insert
M8x50 mm screw
M8x30 mm screw
Locknut M8
Washer
Spacer
Operating manual
GB | 25
