Aqua Forte Vario1.1 Gebrauchs- Und Installationsanleitung Seite 39

b) Ersatzteilliste
NO. Name (engl.)
1 Union Collar
2 Slip Adapter
3 O-Ring
4 Drain Plug
5 O-Ring
6 Pump Body
7 Strainer Basket
8 O-Ring
9 Transparent Lid
10 Nut For Lid
11 O-Ring
12 O-Ring
13 Diffuser
14 Activities Rings
15 Impeller Nut
All manuals and user guides at all-guides.com
Menge NO.
2 16
2 17
2 18
2 19
1 20
1 21
1 22
1 23
1 24
1 25
1 26
1 27
1 28 Cross recessed pan head tapping Screws
1 29
1
Name (engl.)
Flat Key
O-Ring
Impeller
Mechanical Seal
Seal Plate
Washer
Hexagon bolt
Motor
Washer
Hexagon bolt
Motor Support Plastic Sterips
Base
Programmable Controller
Menge
1
1
1
1
1
8
8
1
4
4
1
1
1
1
