User manual
Q-TOOL
P12XL
1.
Battery-powered punch tool to make hexagonal holes
1.1
Capacity
Type Q-Tool P12XL capable of making hexagonal holes from round holes M4, M5, M6 and M8,
depending on the configuration purchased.
Hole diameter
Aluminium
[mm]
[mm]
M4
6.2
2.5
M5
7.2
5.0
M6
9.3
5.0
M8
11.5
5.0
1.2
Accessories
1x Spanner for changing the anvils
2x 20.0 V 2.0 Ah/5 cell batteries
1x Battery charger
1.3
Technical data
Type Q-Tool P12XL
Weight:
1.72 kg [excl. battery]
Stroke:
27.0 mm [1.062'']
Drive:
20V brushless DC motor
Traction force:
20,000 N [4.496 lbs]
4
Steel
Stainless steel
[mm]
[mm]
2.0
2.0
3.0
2.0
3.0
2.0
3.0
2.0
Q-Tool P12XL - Operating manual
1.4
Parts list
Type Q-Tool P12XL, see fig. A/B
Qonnect Code
Description
0503QP12XL
Q-Tool P12XL Battery-powered Hexagonal punch tool
04HA410M4
Q-P12XL Anvil M4
04HA410M5
Q-P12XL Anvil M5
04HA410M6
Q-P12XL Anvil M6
04HA410M8
Q-P12XL Anvil M8
0504QP102
Q-P12XL Punch case M4-M8
0504QP107
Q-P12XL Front sleeve
0504QP104
Q-P12XL Punch M4
0504QP105
Q-P12XL Punch M5
0504QP106
Q-P12XL Punch M6
0504QP108
Q-P12XL Punch M8
0504QP100
Q-P12XL Punch rod
0504QP109
Q-P12XL Punch rod knob
0504QR222-M13
Q-P12XL Spring sleeve [M13]
0504QR222A
Q-P12XL Spring sleeve scraper ring
0504QR222B
Q-P12XL Spring sleeve O-ring
0504QR223-9mm
Q-P12XL [9mm] Mandrel release tube ex O-ring
0504QP101
Q-P12XL Body end cap
0504QP225
Q-P12XL PCB set
0504QR226
Q-P12XL Brushless DC motor
0504QR227
Q-P12XL Mechanical transmission
0504QR228
Q-P12XL Body [right & left]
0504QNR201
Q-XL 5-cell 20V battery 2.0 Ah
0504QNR203
Q-XL Trigger spring
0504QNR204
Q-XL Trigger
0504QNR205
Q-XL Hanging hook
0504QNR202
Q-XL Battery charger
CAUTION: The 0504QNR202 battery charger is equipped with a European plug as standard. If a
different version is required, contact the dealer or manufacturer's representative.
qonnect-fasteners.com
No. Fig. A/B
1
1
1
1
2
3
4
4
4
4
5
6
7
7a
7b
8
9
10
11
12
13
14
15
16
17
5
