Gerätebeschreibung
Der Kindermann Multishare 31 - HDBT Transmitter ist ein Multiformat Signalwandler mit HDMI, VGA und
Display Port (DP) Eingängen und einem HDBT Ausgang. HDBT kann unkomprimierte Video-, Audio-Da-
ten, sowie Steuerbefehle (IR, RS232) gleichzeitig über ein Cat-6 Kabel (AWG 23) bis 70 m weit über-
tragen. Ein unabhängiger Audio-Eingang kann in die Signale der Video-Eingänge eingebettet werden.
Das Gerät kann über Tastendruck, eingebauten Web-Server, RS232 und verschiedene Kontakt-Eingänge
gesteuert werden.
The Kindermann Multishare 31 - HDBT Transmitter is a multi-format switcher with HDMI, VGA and Display
Port inputs to HDBT output. The audio port is independent and could be embedded into any of the video
signal and send it to the far end. The product support web server and it could be controlled by the but-
ton, LAN, RS232, contact closure. IR and RS232 can pass through.
Lieferumfang
- Contents
•
1 x Kindermann Multishare 31 - HDBT Transmitter
•
1 x 24V, 1A DC Netzteil
•
2 x Befestigungswinkel zur Montage
•
1 x Bedienungsanleitung
•
1 x Kindermann Multishare 31 - HDBT transmitter
•
1 x 24V 1A DC power adapter
•
2 x Wall mounting bracket
•
1 x Operating instruction
Sicherheitshinweise
•
Bitte die Anleitung sorgfältig durchlesen und aufbewahren
•
Signalwandler dürfen nur mit Sicherheitskleinspannung betrieben werden
•
Das System darf nur in trockenen, geschlossenen Räumen gelagert und eingesetzt werden
•
Bitte beachten Sie die Sicherheitshinweise der anzuschließenden Geräte
•
Please read the instructions carefully and store them
•
The switch must be operated at safety low voltage
•
The unit may only be stored and used in a dry place
•
Please note the safety instructions of the connected equipment
2
- Specification
- Safety instructions
