CONNECTIONS

Power rail
connections
91 92 93 94 95
Error
Gnd.
+24 V
NC = no connection
NAMUR sensor
41 42 43 44
NAMUR sensor
51 52 53 54
Relay, N.C.
11 12 13 14
Relay, N.C.
11 12 13 14
NC NC
Inputs:
Switch, cable fault
41 42 43 44
R s
Switch, cable fault
51 52 53 54
R s
Outputs:
Relay, N.O.
11 12 13 14
Relay, N.O.
11 12 13 14
9202 - Product Version 9202-001
Supply and
status relay
31 32 33 34
Gnd.
+24 V
R p
R p = 15
R s = 750
R p
Opto, NPN
11 12 13 14
Opto, NPN
11 12 13 14
N.C.
kΩ
Ω
33
