WYBOT C1 Pro Benutzerhandbuch Seite 8

After rinsing, put the filter basket into
the cleaner and close the cover.
DEVICE SPECIFICATION
Name WYBOT C1 Pro(OS7010)
Max. 150㎡
Pool Size
13ft (4m)
Depth
Device Dimension
372(L)*360(W)*240(H) mm
Weight 7,8kg
Runtime
120min.~150min.
2,5 hours
Charging Time
Power
65W
100-240V, 50-60Hz
Charger Input
Charger Output 25,2V/2,6A
4600mAh
Battery Capacity
180µm
Filter
Flow Rate
11,5 m³/H
Moving Speed 11m/min
Water Resistance IPX8
App Connection Available
OTA Update Available
09
5
WYBOT C1 Max(OS7010 Max)
Max. 200㎡
13ft (4m)
372(L)*360(W)*240(H) mm
7,8kg
180min.~210min.
3,5 hours
65W
100-240V, 50-60Hz
25,2V/2,6A
7800mAh
180µm
11,5 m³/H
11m/min
IPX8
Available
Available
LIMITED WARRANTY
1. All WYBOT pool cleaners in the market have been inspected and licensed to be
sold as per local laws.
2. The warranty duration for battery, motor and PCB is two (2) years from the purchas
ing date. Consumable parts, including filter basket, brush, wheels etc., are beyond
warranty.
3. The warranty apply only to original buyers, and not valid to resale and any other
kinds of transfer.
4. Any damages to the unit caused by improper use, unauthorized repair or disas-
sembly are not covered by WYBOTICS Co., Ltd.'s warranty.
5.The order number or record must be presented for any claim or repair within the
warranty period.
HOW TO MAINTAIN YOUR DEVICE
You should follow the steps to store your cleaner to maintain good performance.
a) Ensure the device is powered off
b) Dry out the cleaner and filter basket
c) Fully charge the battery
d) Store the cleaner in a cool and ventilated place, away from direct sunshine,
heat source, frost and squeezing with an ambient temperature between 5℃/ 41
℉ and 45℃ / 113℉.
e) Charge the cleaner every three months to ensure an optimal battery life.
Note:
If your device do not work after a long-term low battery life or being off, please
contact after-sale team for help. For your safety, do not try to disassemble it
without authorization.
FAQ & TROUBLE SHOOTING
Q: What pool shapes and construction materials is the cleaner suitable for?
A: The machine can be applied to rectangle, oval, or irregular shapes of in-ground
swimming pools. Applicable construction materials include PVC, gunite and other
high friction materials. (Slippery materials such as tiles, mosaics, and acrylic may
not work well, and you need to do some modification.)
Q: Will obstacles such as steps, shallow water areas, drains, slopes etc. in the swim-
ming pool affect the running?
A: The machine can climb steps, drains, and shallow water areas.
If you encounter the following situations when using the cleaner, you can check
the table and solve them by yourself.
Note:
If you can not find a solution from the table, please contact after-sale team.
10
