Abmaße / Dimensions (L x B x H)
2
Gewicht / Weight
Material (Deckel /Top)
Material (Boden / Base)
Material (Halterung / Holders)
Material (EasyMountSytem)
Gewinde / Threads
Temperaturfest bis /
temperature resistant to
Kompatibilität / Compatibility (INTEL)
Kompatibilität / Compatibility
(INTEL Narrow ILM)
Kompatibilität / Compatibility (AMD)

2. Vorbereitung der Installation

Sollte bereits ein CPU Kühler auf dem
Mainboard verbaut sein, so muss dieser zuerst
samt zugehörigem Montagematerial entfernt
werden. Anschließend sollte die CPU von alter
Wärmeleitpaste befreit werden.
Vor Installation muss die CPU gleichmäßig mit
einer Wärmeleitpaste versehen werden.
Handelt es sich um eine Erstinstallation des
HEATKILLER® IV wird ein Zugang zur
Rückseite des Mainboards benötigt (gilt nicht
für Sockel 2011). Sollte Ihr Gehäuse über
keinen entsprechenden Ausschnitt verfügen,
muss das Mainboard für die erste Montage

Technische Daten / Technical Data

66 x 59 x 17 mm
420g mit Metall Deckel (with metal top)
180g mit Kunststoff Deckel ( with plastic top)
Kupfer (copper), Messing (brass), Acryl GS (PLEXIGLAS),
POM (Acetal)
Kupfer (copper)
Edelstahl (stainless steel)
Messing vernickelt (nickel plated brass)
2x G¼"
(PRO) 95°C
(BASIC) 80°C
1150, 1151, 1155, 1156, 1366, 2011, 2011-3, 2066
2011 Narrow ILM, 2011-3 Narrow ILM
939, 940, AM2, AM2+, AM3, AM3 +, FM2, FM2+. AM4

2. Before installation

If there is a CPU heat sink installed already,
remove all belonging parts and all leftover
thermal paste. Apply fresh thermal paste prior
to installation of the new cooler.
In case of a first time installation of the
HEATKILLER IV, you need to access the back
of your mainboard (not Socket 2011). If your
computer case doesn't provide an access,
you may have to remove your mainboard from
the case. Further installation steps of the
cooler
don't
require
anymore.
backside
access
