Press the "FUNCTION" button briefly once again to go to the next dimming mode
For trailing edge mode, the LED flashes yellow twice: This mode is most suitable for LED lamps and lamps
with an electronic dimmable transformer
Press the "FUNCTION" button briefly once again to go to the next dimming mode
For PWM (Pulse-width modulation) mode, the LED flashes yellow three times: This mode is often most
suitable for dimming Filament LED lamps
Press the "FUNCTION" button on the dimmer for 3 seconds to confirm the selection.
C
The dimmer is set to trailing edge by default.
14 ADJUSTING THE DIMMING RANGE
If the connected LED lighting does not dim deep enough or vibrates, you can adjust the lower limit of the
dimming range.
Turn on the lamp and set it to 100% brightness.
A
Hold the "FUNCTION" button on the dimmer for 3 seconds. The lamp will go to the lowest brightness.
B
Then release the button.
Shortly press the "FUNCTION" button on the dimmer to lower the minimum brightness.
C
The minimum brightness starts at position 1. Every time the "FUNCTION" button on the dimmer is pressed
shortly, the lamp will dim 1 position deeper (1-2-3-4). If you press the "FUNCTION" button shortly again after
position 4, the minimum dimming position will return to position 1.
Hold the "FUNCTION" button on the dimmer down for 3 seconds again when the correct dimming range
D
has been selected.
The lamp will go ON-OFF-ON-OFF to confirm the selected dimming position.
E
