RPT-20T
Sensor
1 - VCC
1 - Out
1 - GND
2 - VCC
2 - Out
2 - GND
TECHNICAL DATA
Supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24VDC +/-10%
Cable dimensions . . . . . . . . . . . . . . . . . . . . . . . 10 x max. 0,75 mm²
Relative humidity . . . . . . . . . . . . . . . . . . . . 0-95% (non-condensing)
Operating temperature . . . . . . . . . . . . . . . . . . . . . . . . . . -10/+40°C
Enclosure rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . IP21 (EN 60529)
Connection . . . . . . . . . . . . . . . . 1xRJ12 6P4C, 10x screw terminals
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 82x82x41 mm.; see fig. 2
Mounted depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 mm.
Max. Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . .775 mW
Standby Power cumption . . . . . . . . . . . . . . . . . . . . . . . . . . .500 mW
SERVICE AND MAINTENANCE
The RPT-20T Room panel contains no parts which require service
or maintenance.
Please contact your supplier in case of problems.
Disclaimer
OJ cannot be held liable for any errors in the material. OJ reserves
the right to alter its products without notice. This also applies to
products already on order, provided that such alterations can be
made without requiring subsequent changes in specifications
already agreed. The contents of this material may be subject to
copyright and other intellectual property rights and is either the
property of or used under license by OJ Electronics.
The OJ trademark is a registered trademark of OJ Electronics A/S.
8
Screw terminal
+24V out (CH1)
0-10V in (CH1)
GND (CH1)
+24V out (CH2)
0-10V in (CH2)
GND (CH2)
© 2022 OJ Electronics A/S
English
