RF Rx SW868/SW915/SW917/SW922-1W 24VAC/DC
Montage- und Anschlussanleitung / Funk-Empfänger
Mounting and wiring instructions / Wireless receiver
English
LBT Blink code LED 1
(Listen Before Talk)
Off 2 – 1
On (default) 2 – 2
Status signal interval
A regular status telegram can be configured to monitor the wireless
switches at intervals of 10, 100, 1,000 and 10,000 seconds. The additio-
nal telegrams reduce the battery life of the wireless switches.
Status signal Blink code
interval LED 1
Off (default) 3 – 1
10s 3 – 2
100s 3 – 3
1000s 3 – 4
10000s 3 – 5
Attention! If the jumper is set to an interval, wireless switches with
hardware jumpers cannot be reconfigured.

Restore factory settings

This option restores the following factory configuration:
Relay function
Transmitter function
LBT (Listen Before Talk)
Status signal intervall
Taught-in wireless switch IDs are not deleted!
Restore factory settings
Cancel
Confirm
Teaching in of transmitters
The output of the receiver can be switched by a maximum of 40 trans-
mitters. To do this, teach in each transmitter once in the receiver.
- Press push-button S1 → LED MD flashes slowly (2 Hz).
- Actuate transmitter to be taught in
→ LED 1 lights up for a short time.
- To leave teach-in mode: press push-button S1 approx. 1 s
→ LED MD lights up.
Function
Anti-collision
switched off
Anti-collision
switched on
Function
No status signal
Every 10 s
Every 100 s
Every 1,000 s
Every 10,000 s
Standard
Standard
On
Off
Blink code LED 1
4 – 1
4 – 2
Deleting one transmitter
- Press push-button S1 for approx. 1 s
→ LED MD flashes slowly (2 Hz) → Teach-in mode active.
- Release the S1 button → LED 1 lights up.
- Press push-button S1 for 5 s → LED MD flashes fast (5 Hz)
→ Delete mode active.
- Actuate transmitter to be deleted → LED 1 lights up for a short time.
- To leave delete mode: press push-button S1 for approx. 1 s
→ LED MD is green.
Inverse teaching in of one transmitter
- Procedure like teach-in but transmitter must be actuated before pro-
cedure is started by pressing S1.

Deleting all transmitters

- Press push-button S1 for approx. 1 s
→ LED MD flashes slowly (2 Hz) → Teach-in mode active.
- Release the S1 button → LED 1 lights up.
- Press push-button S1 for 5 s → LED MD flashes fast (5 Hz)
→ Delete mode active.
- Press push-button S1 again for 5 s until LED MD is off.
- LED MD lights up and LED 1 is off.
Maintenance and cleaning
.steute recommends routine maintenance as follows:
1. Remove all dirt particles: Clean enclosure on the outside only.
Clean device in accordance with IP protection class. Clean with
a soft cloth and water or a mild detergent. Do not clean using com-
pressed air.
2. Replace damaged parts.
3. Test the function.
Disposal
- Observe national, local and legal regulations concerning disposal.
- Recycle each material separately.
6 / 12
