1.3 5G Statement
The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the poten-
tial for harmful interference to co-channel mobile satellite systems;
For devices with detachable anterna(s), the maximm antenna gain peruitted for devices in the
bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with
the e.i.r.p. limit.
1.4 MPE Requirements
To satisfy FCC / IC RF exposure requirements, a separation distance of 20 cm or more should be
maintained between the antenna of this device and persons during device operation. To ensure
compliance, operation closer than this distance is not recommended.
Under normal use conditions, this equipment should be kept a separation distance of at least
20cm between the antenna and the body of the user.
1.5 CEC
Press and hold "Custom Mode" button for about 20s to enable CEC Mode. And press any button to
disable it.
1.6 Sensor Description
Sensor
AI Vision Sensor
Ultrasonic Sensor
TOF Sensor
Water Press Sensor
Al vision sensor: It is used for collecting pictures and identifying
object types in the pictures through Al algorithm, which is used to
improve the cleaning effect.
Model: XBC20E70 V3, Specification: 640H*480V@10bit 180fps,
Test distance: Max 70cm.
Ultrasonic sensor, after directional transmission of ultrasonic
wave, can roughly distinguish different objects according to the
echo value, and can also be used to measure the distance of
surrounding objects.
Model: AW-UD1000DV3.3.0-2S5-3L1001,
Specification: Test distance: 60-2000mm.
Infrared light wave edge sensor used for mapping, directional
emission of infrared light wave, according to whether there is
reflection and reflection strength to judge the pool edge.
Model: A05, Specification: Max 1000mm in water.
Water Pressure Sensor measures the water pressure to calculate
the water depth, and can also measure water temperature.
Model: LIGOFA05LRYT4-02, Specification: 75-150kpa, -40-125°C.
3
