No load speed (drill mode)
Gear 1
Gear 2
Clutch (positions)
Maximum torque
Maximum drilling capacity
in wood
Maximum drilling capacity
in metal
Weight (According to EPTA
procedure 01/2003)
Weight - not incl. battery pack
Ambient operating and storage
temperature for the tool and
battery pack
(Limited
performance
at
temperatures <0°C)
Recommended ambient
charging temperature
Recommended battery type
Recommended charger
Know Your Product
See page 3.
1. Keyless chuck
2. Torque adjustment ring
3. Gear selector
4. Direction of rotation selector
5. Trigger switch
6. Handle, insulated gripping surface
7. LED light
8. Battery pack
9. Belt clip
10. Auxiliary handle, insulated gripping surface
11. Mode selector (ABS 18 POWER COMBI only)
LED Indicator
If the LED light shows an interrupted fl ashing pattern, this is due to an
overload or overheating of the system.
Overloads can be remedied by releasing the switch and pressing it
again and/or by reconnecting the battery pack.
If the LED light continues to show an interrupted fl ashing pattern,
please allow the product to cool down.
If the malfunction persists over a longer period of time, please contact
your Würth Service.
Intended Use
The drill can be used for drilling into various materials, including
wood, metal, and plastics using a drill bit having a shank diameter of
less than 13 mm. The product can be used to drive and remove screws
and bolts using an appropriate bit.
For damage caused by usage other than intended, the user is
responsible.
0-550 min
0-550 min
-1
-1
0-2000 min
0-2000 min
-1
-1
20 + drill mode
24
140 Nm
140 Nm
40 mm
40 mm
13 mm
13 mm
1.9 kg
1.9 kg
1.62 kg
1.65 kg
-15 - 40°C
-15 - 40°C
5 - 40°C
5 - 40°C
LI 18V/2 Ah BASIC
LI 18V/4 Ah BASIC
LI 18V/5 Ah BASIC
ALG 18/4 BASIC
ALG 18/6 FAST
Symbols
Read all safety warnings and all instructions.
Warning
V
Volts
Direct current
No-load speed
CE conformity
British Conformity Mark
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
local authority or retailer for recycling advice.
Battery
A battery that is new or has not been used for a longer period does
not develop its full capacity until after approx. 2 – 3 charging/
discharging cycles.
Do not place down the battery on radiators or expose it to intense
sunlight for longer periods; temperatures above 50 °C cause damage.
Keep the contacts/terminals of the charger and replaceable battery
clean. For optimal service life, fully charge the battery after use.
Dust Extraction
Dusts from materials such as lead-containing coatings, some wood
types, minerals and metal can be harmful to one's health. Touching
or breathing-in the dusts can cause allergic reactions and/or lead to
respiratory infections of the user or bystanders.
Certain dusts, such as oak or beech dust, are considered carcinogenic,
especially in connection with wood-treatment additives (chromate,
wood preservative). Materials containing asbestos may only be
worked on by specialists.
□ Provide for good ventilation of the working place.
□ It is recommended to wear a P2 fi lter-class respirator.
Observe the relevant regulations in your country for the materials
being worked on.
Maintenance and Cleaning
□ Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories or storing power tools. Such preventive
16
