GB
Application
Infrared urinal fitting, suitable for:
• direct connection to cold water supply
Safety notes
• Installation is only possible in frost-free rooms.
• Use only genuine replacement parts and
accessories. The use of other parts will result in
voiding of the warranty and the CE marking.
Technical data
• Flow pressure:
- min.
- recommended
• Operating pressure:
• Test pressure:
If static pressures exceed 0.5 MPa, a pressure-
reducing valve must be installed.
• Flow rate at 0.1 - 0.4 MPa:
• Temperature:
• Voltage supply:
6V lithium battery type CR-P2
• Flow volume (1 - 7 l adjustable):
• Minimum delay (2 - 10 s adjustable):
• Type of protection:
General functions
• Remaining battery capacity:
Programme 1 functions (factory setting)
• Cleaning mode:
• Automatic flushing (24h):
• Detection zone according to Kodak Gray
Card, grey side, 8x10", landscape:
• Pre-flushing:
• Intermediate flushing:
Further pre-set programmes can be selected via
the sensor system, see the programme table on
page 6.
Special accessories
Further settings and special functions are available
via the infrared remote control (Prod. no. 36 206).
Approval and conformity
This product conforms to the
requirements of the relevant EU
directives.
The conformity declarations can be obtained from
the following address:
GROHE Deutschland Vertriebs GmbH
Zur Porta 9
D-32457 Porta Westfalica
Installation
Flush pipes thoroughly before and after
installation (observe EN 806)!
Refer to the dimensional drawing on fold-out
page I.
Convert fitting, see Fig. [1] - [2].
New installation, see Fig. [3] - [4].
0.05 MPa
Final installation, see Fig. [5] - [9].
0.1 - 0.5 MPa
Open water supply and check that connections
max. 1 MPa
are watertight.
1 MPa
Operation
0.3 - 0.7 l/s
The infrared electronics emits invisible pulsed light.
max. 40 °C
If this light is reflected by a user for a minimum of
5 seconds (minimum delay) and is then received
3 l
again by the electronics, the bowl is flushed after
5 s
the user moves away.
IP 55
The detection zone is dependent upon the
reflective properties of the object.
Activating cleaning mode
readable
• Only possible when temporary shutoff is
activated.
activatable
• The detection zone must kept clear.
activated
1.
Hold finger against the lower area of the
45cm
deactivated
activated
███████████████████████ █▌ █▌ █▌ █▌
2.
Remove finger from the sensor system while
Cleaning mode is active for 3 minutes. The
indicator lamp flashes during this time.
Terminating cleaning mode prematurely.
1.
Hold finger against the lower area of the
███████████████████████______
2.
Remove finger from the sensor system while
sensor system, see Fig. [10].
Indicator lamp signals:
is displayed.
█▌ █▌ █▌
sensor system, see Fig. [10].
Indicator lamp signals:
is displayed.
____
Cleaning mode is terminated.
