Lupine BETTY TL2 Bedienungsanleitung Seite 15

Special Functions
Adjusting backlight low-battery warning:
Use this program to adjust the onset of the low-battery warning.
Press and hold the button, until 3 green
1.
 release the button
The threshold can be selected as shown below.
2.
Backlight:
blue green
6.0 V 5.6 V
6.2 V 5.8 V
Default setting 6.4 V 6.0 V
6.6 V 6.2 V
6.8 V 6.4 V
Recover factory settings:
1.
Press and hold the button, until 5
red LEDs turn on.
release the button

2.
Disconnect the battery, and all factory settings will be restored.
28
LEDs light up.
red
5.2 V
5.3 V
5.4 V
5.5 V
5.6 V
1/4 Inch Adapter:
The adapter allows to mount the light on a tripod.
Use the screws which came with the adapter to
connect it to the light.
Filtercap:
The special cap comes with an additional thread.
Thanks to the cap 55 mm filters, such as available
as foto accessories can be used.
Accessoires
Diffusor for camera:
Art. No. 892 Diffusor
Note: Filters are not supplied with the light.
29
