Alpha 400 Handbook
Valid voltage ranges for @ and @/@ for each module are as follows:
Module Voltage Range
AA @ = 4.5 – 7V
A @ = 4.5 – 6V
AL @ = 4.75 – 5.3V
BB @ = 4.5 – 7V
B @ = 4.5 – 6V
C, CC @ = 5 – 16V
CL @ = 4.6 – 5.6V
CM @ = 5 – 7V
CH @ = 11.4 – 13.5V
D, DD @ = 18 – 29V
E @/@ = 5 – 16V / 5 – 16V
EB @/@ = 4.5 – 5.5V / 4.5 – 5.5V
EQ @/@ = 4.5 – 5.5V / 2.7 – 3.9V
EL @ = 5 – 7V / 11 – 13V
EH @ = 11 – 13V / 11 – 13V
F, FF @ = 9 – 16V
Secondary Options:
Option Description
_MG Provides a module good signal with indicates output voltage is within limits.
_PA, RJ Forces paralleled modules to share load current. Additionally it also provides the module
good signal.
_PP, PJ Provides either of the following functions:
a) Reduces module current limit and caters for paralleled modules with busbar linking. For
use with modules providing a max output of up to 16V only; or
b) Identical to _PA except that the module is paralleled at the output of the module with
busbar linking.
_IN, IJ Provides an external signal which may be used to inhibit the output of the module.
_RP Provides remote programming of the module output voltage.
RPA Provides voltage programming of the module output voltage only.
RPB Provides voltage programming of the module output voltage and has an output VA limiting
circuit.
RPC Provides an output VA limiting circuit
RPD Provides voltage programming of the module output voltage and has an output VA limiting
circuit.
Note:
The RPA option can only be used on modules with output voltages rated up to 32V.
The RP, RPB, RPC and RPD options can only be used on modules with output voltages rated up to 16V.
Not for use with a module voltage range of 18-29V or twin output modules.
ELECTRICAL & THERMAL RATINGS:
Input parameters
NOMINAL INPUT VOLTAGE RANGE
MAX. INPUT VOLTAGE RANGE
INPUT FREQUENCY
MAXIMUM INPUT CURRENT
INRUSH CURRENT
Output parameters
CONFIGURATION
Configurations with one or more A, AA, R or T
modules
Configurations with one or more F modules
PSU's with Low Speed Fan (LSF) Option
PSU's with Reverse Air (RA) Option
Use of input/output connector mouldings
Use of input/output connector mouldings
Module Voltage Range
G, GG @ = 17.5 – 29V
H @/@ = 18 – 32V / 18 – 32V
J, JJ @ = 30 – 48V
K, KK @ = 18 – 31V
L, LL @ = 1.8 – 3.2V
M, MM @ = 5 – 16V
N, NN @ = 18 – 32V
P @/@ = 18 – 29V / 5 – 16V
PL @ = 22 – 26 / 5 – 7V
Q, QQ @ = 2. 7 – 3.9V
R, RR @ = 2. 7 – 3.9V
S, SS @ = 1 – 5.7V
T, TT @ = 1.8 – 3.2V
U, UU @ = 10 – 21V
W, WW @ = 4.5 – 5.5V
Z, ZZ @ = 4.5 – 5.7V
100 - 240VAC
90-264VAC
47-63Hz
7 AMPS
<50 AMPS
ORIENTATION
Vertical with airflow downwards
Vertical with airflow downwards
All, except vertical with fan at top
Horizontal only
All, except vertical with airflow
downwards
Vertical with airflow downwards
Page 15 of 26
MAX. AMPERE-
MAX. POWER
TURNS
350W
375W
155W
300W
80 + (3.2 x Vin)
14.7 + (3.67 x
Vin)
17128 issue 34, June 2012
80
80
30
60
80
80
